Product Description
Backed by Doosan's global reputation for durability, this 2016 DH80 mini excavator delivers proven performance for contractors seeking reliable 8-ton capacity equipment. Powered by a robust Kubota V3300-DI engine producing 45.8kW at 2200rpm, this machine combines fuel efficiency (163g/ps.hr) with the hydraulic muscle to tackle demanding jobsites. With 55kN bucket digging force and a maximum digging depth of 4060mm, it handles trenching, utility work, and site preparation with confidence.
Doosan's extensive dealer network ensures parts availability remains strong even for used models, protecting your investment and minimizing downtime. Currently located in Fuzhou, Fujian, this DH80 features factory-standard hydraulic breaker plumbing, a 0.28-0.32m³ bucket capacity, and compact dimensions (5920mm transport length, 2200mm width) for excellent maneuverability in confined spaces. The water-cooled system and proven joint-venture manufacturing from Yantai guarantee long-term reliability.
Key advantages:
- Strong resale value thanks to Doosan brand recognition
- Readily available Kubota engine parts worldwide
- 6170mm maximum digging radius for versatile reach
- Compact 1710mm
| Specifications | Value |
|---|---|
| No. | 1018957 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7830 |
| Bucket capacity (m³) | 0.28-0.32 |
| Boom length (mm) | 3100 |
| Rod length (mm) | 1800 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Kubota KubotaV3300-DI |
| Rated power (kw/rpm) | 45.8/2200 |
| Cooling mode | water-cooling |
| Displacement (L) | 3.318 |
| Working form | Fuel consumption is 163g/ps.hr |
| Bucket digging force (kN) | 55 |
| Rod digging force (kN) | 38 |
| Maximum flow of main pump (l/min) | 162.8 |
| Traveling Hydraulic Circuit (Mpa) | 250 |
| Rotary Hydraulic Circuit (Mpa) | 190 |
| Hydraulic crushing pipeline is standard | is |
| Bucket cylinders - Number × diameter × stroke (mm) | 85*55*715 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 95*60*850 |
| Boom cylinders - Number × diameter × stroke (mm) | 110*65*865 |
| Total transport length (mm) | 5920 |
| Total transport width (mm) | 2200 |
| Total transport height (mm) | 2585 |
| Full cab height (mm) | 2585 |
| Counterweight ground clearance (mm) | 764 |
| Back end turning radius (mm) | 1710 |
| Total track length (mm) | 2568 |
| Track gauge (mm) | 1650 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2050 |
| Track ground length (mm) | 1990 |
| Maximum digging radius (mm) | 6170 |
| Maximum digging depth (mm) | 4060 |
| Maximum excavation height (mm) | 6918 |
| Maximum unloading height (mm) | 5032 |
