Product Description
Discover the reliability and efficiency of the 2021 Doosan DL305, now available in Zhejiang, China. This used wheel loader is a testament to Doosan's commitment to quality and durability, making it an excellent choice for construction, mining, and material handling operations. Known for its robust performance and ease of maintenance, the DL305 model is designed to handle tough jobs with precision and power. Invest in this machine to enhance your fleet's productivity and reduce operational costs.
- Year: 2021
- Brand: Doosan
- Model: DL305
- Location: Zhejiang, China
| Specifications | Value |
|---|---|
| No. | 1143514 |
| Engine type | |
| Rated power (kw/rpm) | 92/2200 |
| Bucket capacity (m³) | 1.7 |
| Rated load (tons) | |
| Rated load (kg) | 3000 |
| Digging force (lifting force) (kN) | 98 |
| Machine operating weight (kg) | 10500 |
| Max - Unloading height (mm) | 2910 |
| Unloading distance (mm) | 1120 |
| Maximum tractive force (kN) | 100 |
| Maximum climbing ability (°) | 30 |
| Fuel Tank (L) | 150 |
| Hydraulic Tank (L) | 127 |
| Wheelbase (mm) | 2830 |
| Wheel base (mm) | 1850 |
| Minimum ground clearance (mm) | 350 |
| Machine length (mm) | 6950 |
| Machine width (mm) | 2496 |
| Machine height (mm) | 3280 |
| Steering Angle | 40 |
| Minimum turning radius of outer wheel center line | 5250 |
| Turning radius - Outside of bucket (mm) | 5710 |
| Flow rated speed (l/min) | |
| Rated working pressure (bars) | 170/140 |
| Lift (s) | 5.5 |
| Unloading (s) | 1.2 |
| Lower empty bucket (s) | 3.3 |
| Ternary sum (s) | 9.9 |
| Gearbox brand and model | |
| Speed 4 (km/h) | 36/27 |
