Product Description
Engineered for demanding worksite conditions, this 2022 Doosan DL305 wheel loader delivers exceptional operator control and productivity. Powered by a 92kW engine at 2200 rpm, the machine handles a 3000kg rated load with a generous 1.7m³ bucket capacity. Operators benefit from superior visibility across the 6950mm frame, while the 40-degree steering angle and 5710mm turning radius enable precise maneuvering in confined spaces.
Stability remains paramount with a 10,500kg operating weight and 2830mm wheelbase, providing confident handling during material transfer. The hydraulic system operates at 170/140 bar pressure, completing lift cycles in just 5.5 seconds with a 2910mm unloading height. A 30-degree climbing capability and 100kN maximum tractive force ensure reliable performance on challenging terrain.
- Location: Linyi, Shandong
- 98kN digging force for tough applications
- 150L fuel tank for extended operation
- 9.9-second total cycle time maximizes efficiency
- 36 km/h travel speed for rapid repositioning
- 350mm ground clearance handles uneven surfaces
| Specifications | Value |
|---|---|
| No. | 996446 |
| Engine type | |
| Rated power (kw/rpm) | 92/2200 |
| Bucket capacity (m³) | 1.7 |
| Rated load (tons) | |
| Rated load (kg) | 3000 |
| Digging force (lifting force) (kN) | 98 |
| Machine operating weight (kg) | 10500 |
| Max - Unloading height (mm) | 2910 |
| Unloading distance (mm) | 1120 |
| Maximum tractive force (kN) | 100 |
| Maximum climbing ability (°) | 30 |
| Fuel Tank (L) | 150 |
| Hydraulic Tank (L) | 127 |
| Wheelbase (mm) | 2830 |
| Wheel base (mm) | 1850 |
| Minimum ground clearance (mm) | 350 |
| Machine length (mm) | 6950 |
| Machine width (mm) | 2496 |
| Machine height (mm) | 3280 |
| Steering Angle | 40 |
| Minimum turning radius of outer wheel center line | 5250 |
| Turning radius - Outside of bucket (mm) | 5710 |
| Flow rated speed (l/min) | |
| Rated working pressure (bars) | 170/140 |
| Lift (s) | 5.5 |
| Unloading (s) | 1.2 |
| Lower empty bucket (s) | 3.3 |
| Ternary sum (s) | 9.9 |
| Gearbox brand and model | |
| Speed 4 (km/h) | 36/27 |
