Product Description
This 2023 Doosan DL305 wheel loader is currently located in Sichuan, China and available for immediate purchase. The machine comes equipped with a hydraulic hammer attachment and bucket, making it a versatile solution for construction, quarrying, and material handling operations. With minimal operating hours since its 2023 manufacture date, this unit represents excellent value in the used equipment market.
Key features include:
- Year of manufacture: 2023
- Model: Doosan DL305 wheel loader
- Included attachments: hydraulic hammer and bucket
- Current location: Sichuan Province, China
- Condition: used with low hours
The Doosan DL305 is known for its fuel efficiency, operator comfort, and reliable performance in demanding work environments. This package configuration provides immediate operational capability for contractors and operators requiring both loading and breaking functionality.
| Specifications | Value |
|---|---|
| No. | 1086485 |
| Engine type | |
| Rated power (kw/rpm) | 92/2200 |
| Bucket capacity (m³) | 1.7 |
| Rated load (tons) | |
| Rated load (kg) | 3000 |
| Digging force (lifting force) (kN) | 98 |
| Machine operating weight (kg) | 10500 |
| Max - Unloading height (mm) | 2910 |
| Unloading distance (mm) | 1120 |
| Maximum tractive force (kN) | 100 |
| Maximum climbing ability (°) | 30 |
| Fuel Tank (L) | 150 |
| Hydraulic Tank (L) | 127 |
| Wheelbase (mm) | 2830 |
| Wheel base (mm) | 1850 |
| Minimum ground clearance (mm) | 350 |
| Machine length (mm) | 6950 |
| Machine width (mm) | 2496 |
| Machine height (mm) | 3280 |
| Steering Angle | 40 |
| Minimum turning radius of outer wheel center line | 5250 |
| Turning radius - Outside of bucket (mm) | 5710 |
| Flow rated speed (l/min) | |
| Rated working pressure (bars) | 170/140 |
| Lift (s) | 5.5 |
| Unloading (s) | 1.2 |
| Lower empty bucket (s) | 3.3 |
| Ternary sum (s) | 9.9 |
| Gearbox brand and model | |
| Speed 4 (km/h) | 36/27 |
