Product Description
Built for high-capacity material handling and site productivity, this 2010 Doosan DL420 wheel loader arrives ready to execute demanding excavation and loading operations. Powered by a robust 210 kW engine delivering 1275 N·m of maximum torque, this machine combines a substantial 3.9 m³ bucket capacity with an 8,000 kg rated load to move significant volumes efficiently. The 20 kN digging force tackles compacted materials with authority, while the 3,085 mm maximum unloading height enables direct truck loading without repositioning.
- Operating weight: 21,900 kg for stable performance on uneven terrain
- Maximum tractive force: 21.4 kN for reliable traction in challenging conditions
- Top speed: 40 km/h for rapid site-to-site mobility
- Fuel capacity: 367 L for extended operational shifts
- Compact turning radius: 6,875 mm for maneuverability in confined spaces
Currently located in Shandong, this DL420 stands prepared for immediate deployment in quarrying, construction, and bulk material operations requiring dependable loading capacity and operational uptime.
| Specifications | Value |
|---|---|
| No. | 1017065 |
| Rated power (kw/rpm) | 210 |
| Maximum torque (N.m) | 1275 |
| Bucket capacity (m³) | 3.9 |
| Rated load (tons) | |
| Rated load (kg) | 8000 |
| Digging force (lifting force) (kN) | 20 |
| Machine operating weight (kg) | 21900 |
| Max - Unloading height (mm) | 3085 |
| Unloading distance (mm) | 1285 |
| Maximum tractive force (kN) | 21.4 |
| Fuel Tank (L) | 367 |
| Hydraulic Tank (L) | 265 |
| Wheelbase (mm) | 3500 |
| Machine length (mm) | 8890 |
| Machine width (mm) | 3040 |
| Machine height (mm) | 3535 |
| Turning radius - Outside of bucket (mm) | 6875 |
| Maximum speed (km/h) | 40 |
