2011 Doosan DX300LC-9C

1/9
Buy Doosan DX300LC-9C Used Excavator / 1
Buy Doosan DX300LC-9C Used Excavator / 2
Buy Doosan DX300LC-9C Used Excavator / 3
Buy Doosan DX300LC-9C Used Excavator / 4
Buy Doosan DX300LC-9C Used Excavator / 5
Buy Doosan DX300LC-9C Used Excavator / 6
Buy Doosan DX300LC-9C Used Excavator / 7
Buy Doosan DX300LC-9C Used Excavator / 8
Buy Doosan DX300LC-9C Used Excavator / 9

Product Description

Built for contractors who demand reliability across multiple job sites, this 2011 Doosan DX300LC-9C is a proven 30-ton excavator ready to slot directly into active fleet operations. Sourced from Zhejiang, China, and powered by a Doosan DL08 6-cylinder engine rated at 159 kW / 1,900 rpm, this machine delivers consistent hydraulic performance through a dual variable piston pump system outputting 2×248 L/min — keeping productivity high even under demanding load cycles.

  • Bucket Capacity: 1.45 / 1.6 m³ backhoe bucket for versatile dig applications
  • Maximum Digging Depth: 7,275 mm with a maximum digging radius of 10,702 mm
  • Bucket Digging Force: 183.3 kN / Rod Digging Force: 128.4 kN
  • Travel Speed: 5.7 / 3.2 km/h for efficient site repositioning
  • Fuel Tank: 500 L capacity to minimize downtime between refuels
  • Ground Pressure: 0.57 kg/cm² across 600 mm track plates for stable footing
  • Transport Dimensions: 10,615 mm (L) × 3,199 mm (W) × 3,515 mm (H)

Adding this unit as a backup or secondary excavator keeps crews moving when primary machines require maintenance. Available now from Zhejiang, China — contact Fair Trade Machinery for inspection reports and logistics support.

SpecificationsValue
No.1143527
Tonnage (tons)30
Working weight (kg)30215
Bucket capacity (m³)1.45/1.6
Boom length (mm)6245
Rod length (mm)3100
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeDL08
Rated power (kw/rpm)159 / 1,900
Cylinder diameter × stroke (mm)108 *309
Number of cylinders (PCS)6
Ground specific pressure (Kpa)0.57 kg/cm2
Rotation speed (rpm)9.4
Bucket digging force (kN)183.3
Rod digging force (kN)128.4
Travel speed (km/h)5.7 / 3.2
Turning torque (Nm)11760
Maximum flow of main pump (l/min)2*248
Main pump typeVariable piston pump
Fuel Tank (L)500
Hydraulic Tank (L)280
Total transport length (mm)10615
Total transport width (mm)3199
Total transport height (mm)3,515
Counterweight ground clearance (mm)1,150
Minimum ground clearance (mm)506
Back end turning radius (mm)3,188
Total track length (mm)4,940
Track plate width (mm)600
Total track width (mm)3,200
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)9
Number of track plates (single side) (PCS)48
Maximum digging radius (mm)10702
Maximum digging depth (mm)7275
Maximum excavation height (mm)10315
Maximum unloading height (mm)7303
Maximum vertical digging depth (mm)4907
Maximum excavation radius of stop surface (mm)10506
Maximum effective digging depth (mm)6,455
see more

Overview

No.1143527

Brand Name:

Doosan

Model Number:

DX300LC-9C

Year:

2011

Location:

Zhejiang China

Pub Date

Are you interested in this machine?

Please contact us
