Product Description
2019 Doosan DX55W wheeled excavator available from Zhejiang, China. This compact 5.5-ton class machine offers versatility for urban construction, utilities work, and material handling applications. The wheeled configuration provides superior mobility on paved surfaces and eliminates the need for transport trailers on short moves between job sites.
Key features include:
- Wheeled undercarriage for enhanced road mobility
- Compact dimensions suitable for confined work areas
- Doosan diesel engine with reliable performance
- Hydraulic system optimized for digging and lifting tasks
- Operator cabin with ergonomic controls
This unit has been maintained in working condition and is ready for inspection. Video documentation available upon request. Ideal for contractors seeking a maneuverable excavator for municipal, landscaping, or light construction projects.
| Specifications | Value |
|---|---|
| No. | 1121995 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5550 |
| Bucket capacity (m³) | 0.18/0.06 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 4TNV98-E |
| Rated power (kw/rpm) | 40.8/2400 |
| Total displacement (L) | 3.3 |
| Forward speed (Km/h) | 30 |
| Rotation speed (rpm) | 8.7 |
| Main overflow set pressure (Mpa) | 22.5 |
| Fuel Tank (L) | 120 |
| Engine Oil changes (L) | 11.6 |
| Coolant (L) | 10 |
| Hydraulic System (L) | 147.8 |
| Total transport width (mm) | 1920 |
| Full cab height (mm) | 2855 |
| Counterweight ground clearance (mm) | 980 |
| Wheelbase (mm) | 2100 |
| Total tire outside width (mm) | 1920 |
| Minimum ground clearance (mm) | 290 |
| Maximum digging depth (mm) | 3495 |
| Maximum excavation height (mm) | 5980 |
| Maximum unloading height (mm) | 4265 |
