2019 Doosan DX65-9C PLUS

1/6
Buy Doosan DX65-9C PLUS Used Excavator / 1
Buy Doosan DX65-9C PLUS Used Excavator / 2
Buy Doosan DX65-9C PLUS Used Excavator / 3
Buy Doosan DX65-9C PLUS Used Excavator / 4
Buy Doosan DX65-9C PLUS Used Excavator / 5
Buy Doosan DX65-9C PLUS Used Excavator / 6

Product Description

Discover the 2019 Doosan DX65-9C PLUS, a robust and reliable excavator currently available in Zhejiang, China. This machine, known for its efficiency and durability, is offered at an attractive price point just over 50,000 RMB, making it a cost-effective solution for your construction needs. The DX65-9C PLUS is equipped with features that enhance productivity and ease of operation, ideal for various excavation tasks. Its design focuses on operator comfort and safety, ensuring smooth and efficient performance on any job site.

  • Year: 2019
  • Brand: Doosan
  • Model: DX65-9C PLUS
  • Location: Zhejiang, China
  • Pricing: Just over 50,000 RMB
SpecificationsValue
No.1175357
Tonnage (tons)6
Working weight (kg)5730
Bucket capacity (m³)0.23
Boom length (mm)3000
Rod length (mm)1600
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine type4TNV98L
Rated power (kw/rpm)39/2200
Cylinder diameter × stroke (mm)98*110
Number of cylinders (PCS)4
Rotation speed (rpm)9
Bucket digging force (kN)41.2
Rod digging force (kN)27.4
Travel speed (km/h)4.16 / 2.3
Maximum flow of main pump (l/min)2 x 57.8
Main pump typeVariable piston pump
Fuel Tank (L)115
Hydraulic Tank (L)62
Total transport length (mm)5870
Total transport width (mm)2000
Total transport height (mm)2565
Counterweight ground clearance (mm)700
Minimum ground clearance (mm)350
Back end turning radius (mm)1660
Total track length (mm)2540
Track plate width (mm)400
Number of sprockets (single side) (each)1
Number of wheels (single side) (each)5
Number of track plates (single side) (PCS)40
Maximum digging radius (mm)6136
Maximum digging depth (mm)3807
Maximum excavation height (mm)5788
Maximum unloading height (mm)4064
Maximum vertical digging depth (mm)3037
Dodging plate width × height (mm)2000*350
Maximum excavation radius of stop surface (mm)6000
see more

Overview

No.1175357

Brand Name:

Doosan

Model Number:

DX65-9C PLUS

Year:

2019

Location:

Zhejiang China

Pub Date:
