Product Description
Built for precision and power, this 2019 Doosan DX75 mini excavator delivers reliable performance across excavation, grading, and site preparation tasks. Operating at 7 tons with a Yanmar 4TNV94L engine producing 39.7 kW, this machine combines compact dimensions with serious digging capability. Its 53.4 kN bucket digging force and 3,930 mm maximum digging depth handle demanding earthwork while maintaining maneuverability in confined spaces.
- 7-ton working weight with 0.28 m³ bucket capacity
- Maximum digging radius of 6,270 mm for extended reach
- Variable piston pump hydraulics for responsive control
- Compact transport size: 6,030 mm length × 2,100 mm width
- 10.7 rpm rotation speed for efficient positioning
- 111-liter fuel tank for extended operation
- 30° climbing ability for challenging terrain
- Currently located in Lishui, Zhejiang
Site-ready and inspection-welcome, this DX75 arrives equipped for immediate deployment on residential construction, utility installation, and landscaping projects requiring reliable 7-ton class performance.
| Specifications | Value |
|---|---|
| No. | 1015054 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7350 |
| Bucket capacity (m³) | 0.28 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.7 / 2200 |
| Maximum torque (N.m) | 24.6/1475 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct spray |
| Rotation speed (rpm) | 10.7 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 53.4 |
| Rod digging force (kN) | 36.9 |
| Travel speed (km/h) | 3.0 / 4.7 |
| Turning torque (Nm) | 23.4 ~ 24.6 |
| Main pump type | Variable piston pump |
| Fuel Tank (L) | 111 |
| Total transport length (mm) | 6030 |
| Total transport width (mm) | 2100 |
| Total transport height (mm) | 2680(to top of cab) |
| Full cab height (mm) | 2680 |
| Minimum ground clearance (mm) | 370 |
| Minimum turning radius of front working device (mm) | 1745 |
| Back end turning radius (mm) | 1755 |
| Onboard width (mm) | 2130 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1650 |
| Track ground length (mm) | 2110 |
| Maximum digging radius (mm) | 6270 |
| Maximum digging depth (mm) | 3930 |
| Maximum excavation height (mm) | 7050 |
| Maximum unloading height (mm) | 5165 |
| Maximum vertical digging depth (mm) | 2570 |
| Dodging plate width × height (mm) | 2100 x 420 |
| Maximum excavation radius of stop surface (mm) | 6115 |
