Product Description
This 2019 Doosan DX75 mini excavator offers reliable performance for construction and earthmoving applications. Manufactured by Doosan, a trusted name in compact equipment, this machine comes equipped with a front bucket attachment for versatile digging and loading operations. Currently located in Sichuan, China, this unit represents solid value in the 7-ton class excavator segment.
- Year of Manufacture: 2019
- Model: Doosan DX75
- Configuration: Equipped with bucket attachment
- Operating Weight Class: Approximately 7.5 tonnes
- Current Location: Sichuan Province, China
- Application: Suitable for excavation, trenching, and material handling
The DX75 is known for its compact dimensions combined with strong digging force, making it ideal for urban construction sites and infrastructure projects. This used unit is available for inspection and export inquiries.
| Specifications | Value |
|---|---|
| No. | 1166620 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7350 |
| Bucket capacity (m³) | 0.28 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.7 / 2200 |
| Maximum torque (N.m) | 24.6/1475 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct spray |
| Rotation speed (rpm) | 10.7 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 53.4 |
| Rod digging force (kN) | 36.9 |
| Travel speed (km/h) | 3.0 / 4.7 |
| Turning torque (Nm) | 23.4 ~ 24.6 |
| Main pump type | Variable piston pump |
| Fuel Tank (L) | 111 |
| Total transport length (mm) | 6030 |
| Total transport width (mm) | 2100 |
| Total transport height (mm) | 2680(to top of cab) |
| Full cab height (mm) | 2680 |
| Minimum ground clearance (mm) | 370 |
| Minimum turning radius of front working device (mm) | 1745 |
| Back end turning radius (mm) | 1755 |
| Onboard width (mm) | 2130 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1650 |
| Track ground length (mm) | 2110 |
| Maximum digging radius (mm) | 6270 |
| Maximum digging depth (mm) | 3930 |
| Maximum excavation height (mm) | 7050 |
| Maximum unloading height (mm) | 5165 |
| Maximum vertical digging depth (mm) | 2570 |
| Dodging plate width × height (mm) | 2100 x 420 |
| Maximum excavation radius of stop surface (mm) | 6115 |
