Product Description
Featuring a Yanmar 4TNV94L engine, this 2019 Doosan DX75 excavator delivers 39.7 kW of power at 2200 rpm, ensuring robust performance for your construction needs. With a working weight of 7350 kg and a bucket capacity of 0.28 m³, it is designed for efficiency and durability.
- Equipped with a backhoe bucket, the DX75 offers a maximum digging force of 53.4 kN, making it ideal for tough excavation tasks.
- Operators benefit from excellent visibility in the full cab, which stands at 2680 mm, providing a clear view of the work area to enhance safety and precision.
- The machine's 4-stroke, water-cooled, direct spray engine ensures smooth operation and reliable performance, even in challenging conditions.
- With a variable piston pump, the DX75 provides precise control and stability, crucial for maintaining high productivity on any job site.
- Traveling at speeds up to 4.7 km/h, this excavator allows for efficient movement around the site, reducing downtime and increasing overall project efficiency.
| Specifications | Value |
|---|---|
| No. | 994675 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7350 |
| Bucket capacity (m³) | 0.28 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.7 / 2200 |
| Maximum torque (N.m) | 24.6/1475 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct spray |
| Rotation speed (rpm) | 10.7 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 53.4 |
| Rod digging force (kN) | 36.9 |
| Travel speed (km/h) | 3.0 / 4.7 |
| Turning torque (Nm) | 23.4 ~ 24.6 |
| Main pump type | Variable piston pump |
| Fuel Tank (L) | 111 |
| Total transport length (mm) | 6030 |
| Total transport width (mm) | 2100 |
| Total transport height (mm) | 2680(to top of cab) |
| Full cab height (mm) | 2680 |
| Minimum ground clearance (mm) | 370 |
| Minimum turning radius of front working device (mm) | 1745 |
| Back end turning radius (mm) | 1755 |
| Onboard width (mm) | 2130 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1650 |
| Track ground length (mm) | 2110 |
| Maximum digging radius (mm) | 6270 |
| Maximum digging depth (mm) | 3930 |
| Maximum excavation height (mm) | 7050 |
| Maximum unloading height (mm) | 5165 |
| Maximum vertical digging depth (mm) | 2570 |
| Dodging plate width × height (mm) | 2100 x 420 |
| Maximum excavation radius of stop surface (mm) | 6115 |
