Product Description
Built for demanding jobsites, this 2016 Hitachi EX350H-5 delivers proven performance with the reliability that keeps contractors coming back to the Hitachi nameplate. Operating at 35 tons with a robust Isuzu B-6SD1T engine producing 169kW, this excavator handles heavy-duty excavation with a 1.4m³ backhoe bucket and 7,380mm maximum digging depth. Stationed in Hangzhou, Zhejiang, this machine represents exceptional value in the used market.
Why Hitachi retains value:
- Global parts network: Hitachi's extensive dealer support ensures critical components remain accessible years after production
- Proven durability: The EX-5 series is engineered for longevity, reducing downtime and repair frequency
- Strong resale demand: Hitachi excavators consistently command premium prices due to their reputation for reliability
- Service documentation: Comprehensive technical manuals and diagnostic support simplify maintenance planning
With an 11,100mm maximum reach and 560L fuel capacity for extended operation, this EX350H-5 combines productivity with the confidence that comes from investing in a brand recognize
| Specifications | Value |
|---|---|
| No. | 1029679 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 32613.3 |
| Bucket capacity (m³) | 1.4 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu B-6SD1T |
| Rated power (kw/rpm) | 169/1900 |
| Ground specific pressure (Kpa) | 66 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 560 |
| Total transport length (mm) | 10950 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3230 |
| Full cab height (mm) | 3110 |
| Counterweight ground clearance (mm) | 1140 |
| Minimum ground clearance (mm) | 500 |
| Back end turning radius (mm) | 3290 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3730 |
| Maximum digging depth (mm) | 7380 |
| Maximum excavation height (mm) | 10230 |
| Maximum unloading height (mm) | 7130 |
| Maximum vertical digging depth (mm) | 6480 |
| Maximum excavation radius of stop surface (mm) | 11100 |
