Product Description
Secure immediate access to proven excavation power with this 2018 Hitachi EX350H-5, currently positioned in Dezhou, Shandong and available for fast deployment. Rated at 35 tons with a robust Isuzu B-6SD1T engine delivering 169 kW, this machine offers the performance and reliability your project demands without factory wait times. Its 1.4 m³ backhoe bucket, 7,380 mm maximum digging depth, and 11,100 mm excavation radius provide exceptional productivity across diverse applications.
- Operating Weight: 32,613 kg with optimized 66 kPa ground pressure
- Engine: Isuzu B-6SD1T, 169 kW at 1,900 rpm
- Reach & Depth: 11,100 mm max radius, 7,380 mm digging depth
- Fuel Capacity: 560 L tank for extended operational shifts
- Transport Dimensions: 10,950 × 3,190 × 3,230 mm
- Location: Dezhou, Shandong—ready for immediate inspection and dispatch
Skip months of lead time. This joint-venture manufactured excavator is inspection-ready and positioned for rapid mobilization to your site. Contact Fair Trade Machinery today to arrange viewing or coordinate logistics.
| Specifications | Value |
|---|---|
| No. | 1024279 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 32613.3 |
| Bucket capacity (m³) | 1.4 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu B-6SD1T |
| Rated power (kw/rpm) | 169/1900 |
| Ground specific pressure (Kpa) | 66 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 560 |
| Total transport length (mm) | 10950 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3230 |
| Full cab height (mm) | 3110 |
| Counterweight ground clearance (mm) | 1140 |
| Minimum ground clearance (mm) | 500 |
| Back end turning radius (mm) | 3290 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3730 |
| Maximum digging depth (mm) | 7380 |
| Maximum excavation height (mm) | 10230 |
| Maximum unloading height (mm) | 7130 |
| Maximum vertical digging depth (mm) | 6480 |
| Maximum excavation radius of stop surface (mm) | 11100 |
