Product Description
With a robust working weight of 32,613 kg and a powerful Isuzu B-6SD1T engine, this 2021 Hitachi EX350H-5 excavator is an ideal fleet addition for demanding construction projects. Featuring a 35-ton capacity and a 1.4 m³ bucket, it ensures efficient material handling and excavation. For contractors looking to bolster their fleet, this unit offers a reliable 169 kW of power at 1900 rpm, making it a strong backup for high-volume operations.
- Travel speed: 5.5 km/h
- Fuel tank capacity: 560 L
- Maximum digging depth: 7,380 mm
- Maximum unloading height: 7,130 mm
- Ground specific pressure: 66 Kpa
| Specifications | Value |
|---|---|
| No. | 1020738 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 32613.3 |
| Bucket capacity (m³) | 1.4 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu B-6SD1T |
| Rated power (kw/rpm) | 169/1900 |
| Ground specific pressure (Kpa) | 66 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 560 |
| Total transport length (mm) | 10950 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3230 |
| Full cab height (mm) | 3110 |
| Counterweight ground clearance (mm) | 1140 |
| Minimum ground clearance (mm) | 500 |
| Back end turning radius (mm) | 3290 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3730 |
| Maximum digging depth (mm) | 7380 |
| Maximum excavation height (mm) | 10230 |
| Maximum unloading height (mm) | 7130 |
| Maximum vertical digging depth (mm) | 6480 |
| Maximum excavation radius of stop surface (mm) | 11100 |
