Product Description
Engineered for precision and operator confidence, this 2018 Hitachi ZH200-5A hybrid excavator delivers 20-ton performance with exceptional fuel efficiency. Powered by an Isuzu GI-4HK1XKSA-03 engine producing 113 kW at 2000 rpm, the hybrid system reduces fuel consumption while maintaining robust digging force—158 kN bucket force and 114 kN arm force handle demanding excavation tasks with ease.
Operator comfort drives productivity on this machine. The spacious cab offers commanding visibility across a 9920 mm maximum digging radius, while intuitive controls and reduced vibration from the hybrid powertrain minimize fatigue during extended shifts. Ground-level stability comes from 600 mm triple-grooved track plates and 46 Kpa ground pressure, ensuring confident operation on variable terrain. With 11.5 rpm rotation speed and a 2890 mm rear swing radius, positioning accuracy in confined spaces becomes second nature.
- Working Weight: 20,900 kg
- Bucket Capacity: 0.91 m³
- Maximum Digging Depth: 6670 mm
- Hybrid Power System: Superior fuel economy
- Location: Hefei, Anhui
| Specifications | Value |
|---|---|
| No. | 1025079 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.91 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Hybrid power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu GI-4HK1XKSA-03 |
| Rated power (kw/rpm) | 113/2000 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 5.193 |
| Working form | 4 stroke, water cooled, electrically controlled direct injection |
| Ground specific pressure (Kpa) | 46 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 158 |
| Rod digging force (kN) | 114 |
| Travel speed (km/h) | 3.5-5.5 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 200 |
| Engine Oil changes (L) | 23 |
| Total transport length (mm) | 9660 |
| Total transport width (mm) | 2860 |
| Total transport height (mm) | 3010 |
| Full cab height (mm) | 2950 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 450 |
| Minimum turning radius of front working device (mm) | 3180 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4170 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Maximum digging radius (mm) | 9920 |
| Maximum digging depth (mm) | 6670 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 7180 |
| Maximum vertical digging depth (mm) | 5990 |
| Maximum excavation radius of stop surface (mm) | 9750 |
