Product Description
This 2020 Hitachi ZX160W wheeled excavator represents a premium opportunity for contractors seeking reliable performance in urban and infrastructure projects. Imported directly from Japan, this machine features factory-installed 16-meter long reach boom configuration, ideal for deep excavation, slope work, and extended reach applications.
- Year: 2020
- Model: Hitachi ZX160W
- Extended Boom: 16 meters (factory original)
- Wide Track Configuration: 800mm
- Location: Zhejiang, China
The wheeled undercarriage provides excellent mobility between job sites without transport requirements. Well-maintained with strong operational performance, this machine is suitable for utilities installation, road construction, and material handling applications. Available for immediate inspection in Zhejiang province.
| Specifications | Value |
|---|---|
| No. | 1139171 |
| Tonnage (tons) | 17 |
| Working weight (kg) | 17300 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu Isuzu 4BG1XABF |
| Rated power (kw/rpm) | 90.2/2300 |
| Total displacement (L) | 4.3 |
| Forward speed (Km/h) | 32 |
| Rotation speed (rpm) | 13.3 |
| Main overflow set pressure (Mpa) | 34.3359 |
| Fuel Tank (L) | 280 |
| Engine Oil changes (L) | 15.58 |
| Coolant (L) | 19.2 |
| Hydraulic System (L) | 180 |
| Total transport length (mm) | 8510 |
| Total transport width (mm) | 2530 |
| Total transport height (mm) | 3130 |
| Full cab height (mm) | 3045 |
| Counterweight ground clearance (mm) | 1215 |
| Wheelbase (mm) | 2550 |
| Total tire outside width (mm) | 2530 |
| Minimum ground clearance (mm) | 360 |
| Back end turning radius (mm) | 2190 |
| Maximum excavation radius (mm) | 8280 |
| Maximum digging depth (mm) | 4770 |
| Maximum excavation height (mm) | 8730 |
| Maximum unloading height (mm) | 6040 |
| Maximum vertical digging depth (mm) | 4230 |
