Product Description
This 2017 Hitachi ZX170W-3 wheeled excavator offers versatile mobility for urban construction and infrastructure projects. Located in Zhejiang, China, this late-2017 unit combines Hitachi's proven hydraulic systems with the operational flexibility of a wheeled undercarriage.
The ZX170W-3 features:
- Wheeled configuration for rapid site-to-site transit
- Approximately 17-ton operating weight class
- Fuel-efficient engine meeting emission standards
- Spacious operator cabin with ergonomic controls
- Suitable for utility work, road construction, and material handling
This machine represents a practical solution for contractors requiring both excavation capability and road mobility. Inspection recommended prior to purchase. Contact us for detailed specifications, service history, and competitive pricing on this Hitachi wheeled excavator.
| Specifications | Value |
|---|---|
| No. | 1138652 |
| Tonnage (tons) | 17 |
| Working weight (kg) | 17800 |
| Bucket capacity (m³) | 0.7 |
| Rod length (mm) | 2580 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU AI-4HK1X |
| Rated power (kw/rpm) | 107/2000 |
| Total displacement (L) | 5.193 |
| Cooling mode | water-cooling |
| remark | Turbocharged and intercooled |
| Forward speed (Km/h) | Crawling 2.6/ Low speed 8.6/ High speed 35 |
| Rotation speed (rpm) | 12.2 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 83 |
| Rod digging force (kN) | 80 |
| Minimum turning radius (m) | 6650 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Quantitative plunger type ×1 |
| Type of walking hydraulic motor | Variable plunger type x 1 |
| Maximum flow of main pump (l/min) | 200 * 2 + 28.6 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 29.3 |
| Boom cylinder - Cylinder diameter × stroke (mm) | 2-110×80 (piston rod diameter) |
| Bucket rod cylinder - Cylinder diameter × stroke (mm) | 1-120×90 (piston rod diameter) |
| Bucket cylinder - Cylinder diameter × stroke (mm) | 1-105×75 (piston rod diameter) |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable piston type ×2+ gear pump ×1 |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Pilot pump flow (L/min) | 28.6 |
| Fuel Tank (L) | 290 |
| Hydraulic Tank (L) | 100 |
| Engine Oil changes (L) | 23 |
| Coolant (L) | 22 |
| Hydraulic System (L) | 240 |
| Total transport length (mm) | 8580 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3130 |
| Full cab height (mm) | 3130 |
| Counterweight ground clearance (mm) | 1235 |
| Wheelbase (mm) | 2550 |
| Total tire outside width (mm) | 2470 |
| Minimum ground clearance (mm) | 350 |
| Maximum digging radius (mm) | 9050 |
| Maximum excavation radius (mm) | 8870 |
| Maximum digging depth (mm) | 5330 |
| Maximum excavation height (mm) | 9100 |
| Maximum unloading height (mm) | 6360 |
| Maximum vertical digging depth (mm) | 5600 |
| Minimum turning radius (mm) | 2940 |
| Bulldozer lift or depth (mm) | 445 |
| Dodging plate width × height (mm) | 2530 x 590 |
