Product Description
Proven in demanding job sites since 2019, this Hitachi ZX170W-3 wheeled excavator combines Japanese engineering excellence with versatile performance. Operating at 17 tons with a robust 17,800 kg working weight, this machine delivers reliable power through its ISUZU AI-4HK1X turbocharged and intercooled engine, generating 107 kW at 2000 rpm. Built for durability, the ZX170W-3 offers exceptional mobility with a top speed of 35 km/h and impressive 70% climbing ability, making it ideal for urban construction and infrastructure projects.
Key specifications include:
- 0.7 m³ bucket capacity with 83 kN digging force
- Maximum digging reach of 9,050 mm and depth of 5,330 mm
- Dual variable piston pumps (200 L/min each) for responsive hydraulic performance
- Water-cooled 5.193 L engine with proven reliability
- Compact transport dimensions: 8,580 mm length × 2,550 mm width
- 290 L fuel capacity for extended operation
Currently located in Guangzhou, Guangdong, this workhorse represents dependable Japanese manufacturing quality backed by years of field-proven performance.
| Specifications | Value |
|---|---|
| No. | 1031139 |
| Tonnage (tons) | 17 |
| Working weight (kg) | 17800 |
| Bucket capacity (m³) | 0.7 |
| Rod length (mm) | 2580 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU AI-4HK1X |
| Rated power (kw/rpm) | 107/2000 |
| Total displacement (L) | 5.193 |
| Cooling mode | water-cooling |
| remark | Turbocharged and intercooled |
| Forward speed (Km/h) | Crawling 2.6/ Low speed 8.6/ High speed 35 |
| Rotation speed (rpm) | 12.2 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 83 |
| Rod digging force (kN) | 80 |
| Minimum turning radius (m) | 6650 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Quantitative plunger type ×1 |
| Type of walking hydraulic motor | Variable plunger type x 1 |
| Maximum flow of main pump (l/min) | 200 * 2 + 28.6 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 29.3 |
| Boom cylinder - Cylinder diameter × stroke (mm) | 2-110×80 (piston rod diameter) |
| Bucket rod cylinder - Cylinder diameter × stroke (mm) | 1-120×90 (piston rod diameter) |
| Bucket cylinder - Cylinder diameter × stroke (mm) | 1-105×75 (piston rod diameter) |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable piston type ×2+ gear pump ×1 |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Pilot pump flow (L/min) | 28.6 |
| Fuel Tank (L) | 290 |
| Hydraulic Tank (L) | 100 |
| Engine Oil changes (L) | 23 |
| Coolant (L) | 22 |
| Hydraulic System (L) | 240 |
| Total transport length (mm) | 8580 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3130 |
| Full cab height (mm) | 3130 |
| Counterweight ground clearance (mm) | 1235 |
| Wheelbase (mm) | 2550 |
| Total tire outside width (mm) | 2470 |
| Minimum ground clearance (mm) | 350 |
| Maximum digging radius (mm) | 9050 |
| Maximum excavation radius (mm) | 8870 |
| Maximum digging depth (mm) | 5330 |
| Maximum excavation height (mm) | 9100 |
| Maximum unloading height (mm) | 6360 |
| Maximum vertical digging depth (mm) | 5600 |
| Minimum turning radius (mm) | 2940 |
| Bulldozer lift or depth (mm) | 445 |
| Dodging plate width × height (mm) | 2530 x 590 |
