Product Description
Discover the 2017 Hitachi ZX17U-2, a compact and robust excavator, now available in Zhejiang, China. This machine, with its reliable performance and efficient design, is ideal for various construction and excavation projects. The ZX17U-2 is known for its durability and ease of operation, making it a preferred choice for professionals in the industry. Its compact size allows for easy maneuverability in tight spaces, enhancing productivity on any job site.
- Year: 2017
- Brand: Hitachi
- Model: ZX17U-2
- Location: Zhejiang, China
| Specifications | Value |
|---|---|
| No. | 1133035 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1850 |
| Bucket capacity (m³) | 0.020 - 0.050 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 3TNV70 |
| Rated power (kw/rpm) | 11.0/2400 |
| Cylinder diameter × stroke (mm) | 70 x 74 |
| Displacement (L) | 0.854 |
| Bucket digging force (kN) | 16 |
| Rod digging force (kN) | 10.3 |
| Travel speed (km/h) | 2.4-4.3 |
| Turning torque (Nm) | 50.2 |
| Main overflow set pressure (Mpa) | 20.6 |
| Maximum flow of main pump (l/min) | 2 x 19.2 |
| Bucket cylinders - Number × diameter × stroke (mm) | 60 x 94 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 60 x 311 |
| Boom cylinders - Number × diameter × stroke (mm) | 60 x 406 |
| Fuel Tank (L) | 19.5 |
| Engine Oil changes (L) | 3.1 |
| Coolant (L) | 15.7 |
| Total transport length (mm) | 3590 |
| Total transport width (mm) | 980 |
| Total transport height (mm) | 2400 |
| Minimum ground clearance (mm) | 165 |
| Back end turning radius (mm) | 1610 |
| Track gauge (mm) | 1210 |
| Track plate width (mm) | 2230 |
| Maximum digging radius (mm) | 3900 |
| Maximum digging depth (mm) | 2170 |
| Maximum excavation height (mm) | 3560 |
| Maximum unloading height (mm) | 2530 |
