Product Description
This 2017 Hitachi ZX200-5A hydraulic excavator is offered from stock in Anhui, China, and represents a well-kept example of Hitachi's proven 20-tonne class machine. The unit has been inspected and presents in excellent overall condition: mechanical and hydraulic systems are sound, and the undercarriage shows normal wear consistent with its working history. No major repairs are required before it goes back to work.
Documentation is complete and in order, making the machine straightforward to transfer for domestic resale or export. Key points:
- Year: 2017
- Brand / Model: Hitachi ZX200-5A
- Category: 20-tonne class hydraulic excavator
- Location: Anhui, China — available for inspection
- Papers: full set, ready for transfer
- Condition: strong working unit, sold as inspected
Serious buyers are encouraged to move quickly — machines in this condition and with clean paperwork do not stay available long. Additional photographs and inspection arrangements can be provided on request.
| Specifications | Value |
|---|---|
| No. | 1157309 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20200-20300 |
| Bucket capacity (m³) | 0.91~1.0 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu GI-4HK1XKSA-02 |
| Rated power (kw/rpm) | 113/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 115 x 125 |
| Maximum torque (N.m) | 638/1500 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 5.193 |
| Working form | 4-stroke, water-cooled, electronically controlled direct injection, turbocharged, intercooled |
| Ground specific pressure (Kpa) | 45 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 158 |
| Rod digging force (kN) | 114 |
| Travel speed (km/h) | 5.5/3.5 |
| Turning torque (Nm) | 68 |
| Rotary hydraulic motor type | 1 swashplate plunger motor |
| Type of walking hydraulic motor | 2 variable swash plate plunger motor |
| Maximum flow of main pump (l/min) | 2 x 212 + 30.2 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 32.3 |
| Main pump type | 2 variable axial piston pumps +1 gear pump |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 115 x 80 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 135 x 95 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 120 x 85 |
| Fuel Tank (L) | 400.0 |
| Hydraulic Tank (L) | 135.0 |
| Engine Oil changes (L) | 23.0 |
| Hydraulic System (L) | 31.0 |
| Total transport length (mm) | 9660 |
| Total transport width (mm) | 2860 |
| Total transport height (mm) | 3010 |
| Full cab height (mm) | 2950 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 450 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4170 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3370 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 46 |
| Maximum digging radius (mm) | 9920 |
| Maximum digging depth (mm) | 6670 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 7180 |
| Maximum vertical digging depth (mm) | 5990 |
| Maximum excavation radius of stop surface (mm) | 9750 |
