Product Description
Proven performance meets exceptional engineering in this 2019 Hitachi ZX210K-5A excavator, currently located in Hunan. With a robust 21-ton operating weight and powered by a reliable Isuzu GI-4HK1XKSA-02 engine delivering 113kW at 2000rpm, this machine represents a workhorse built to endure demanding jobsite conditions. Four years of operation demonstrate the legendary durability that defines Hitachi's joint venture manufacturing standards.
Engineered for sustained productivity, this backhoe excavator features impressive digging capabilities with 158kN bucket force and 114kN arm force. Its 0.91-1.0m³ bucket capacity, combined with a maximum digging reach of 9920mm and depth of 6670mm, ensures versatile performance across diverse applications. The water-cooled, turbocharged engine with intercooler technology provides consistent power delivery, while dual variable axial piston pumps maintain hydraulic efficiency throughout extended work cycles.
- Operating weight: 21,000-21,100kg with proven stability
- Maximum digging depth: 6,670mm for deep excavation work
- Fuel capacity: 400L for extended operation periods
- 70% climbing ability on challenging terrain
- Established track record since
| Specifications | Value |
|---|---|
| No. | 998033 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21000~21100 |
| Bucket capacity (m³) | 0.91~1.0 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu GI-4HK1XKSA-02 |
| Rated power (kw/rpm) | 113 / 2000 |
| Cooling mode | water-cooling |
| Displacement (L) | 5.193 |
| Working form | 4 stroke, water cooled, electronically controlled injection, turbocharged, intercooled |
| Ground specific pressure (Kpa) | 47 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 158 |
| Rod digging force (kN) | 114 |
| Travel speed (km/h) | 5.5 / 3.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | 1 axial plunger motor |
| Type of walking hydraulic motor | 2 variable axial piston motors |
| Main pump type | 2 variable axial piston pumps, 1 gear pump |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 200 |
| Engine Oil changes (L) | 23 |
| Total transport length (mm) | 9660 |
| Total transport width (mm) | 2880 |
| Total transport height (mm) | 3010 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 450 |
| Minimum turning radius of front working device (mm) | 3180 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4170 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 9920 |
| Maximum digging depth (mm) | 6670 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 7180 |
| Maximum vertical digging depth (mm) | 5990 |
| Maximum excavation radius of stop surface (mm) | 9750 |
