2011 Hitachi ZX330-3G

1/4
Buy Hitachi ZX330-3G Used Excavator / 1
Buy Hitachi ZX330-3G Used Excavator / 2
Buy Hitachi ZX330-3G Used Excavator / 3
Buy Hitachi ZX330-3G Used Excavator / 4

Product Description

Discover the robust and reliable 2011 Hitachi ZX330-3G excavator, available at an attractive price of 105,000 RMB. Located in Zhejiang, China, this used machine is a solid choice for any construction or excavation project. Known for its durability and efficiency, the ZX330-3G model is designed to handle tough jobs with ease, ensuring that your operations run smoothly and efficiently.

  • Year: 2011
  • Brand: Hitachi
  • Model: ZX330-3G
  • Location: Zhejiang, China
  • Price: 105,000 RMB
SpecificationsValue
No.1164526
Tonnage (tons)33
Working weight (kg)3190
Bucket capacity (m³)1.38
Boom length (mm)6.4
Rod length (mm)3.2
Country of originHefei, Anhui Province
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeISUZU Isuzu AA-6HK1XQA
Rated power (kw/rpm)184/2000
Cooling modewater-cooling
Cylinder diameter × stroke (mm)115 x 125
Number of cylinders (PCS)6
Displacement (L)7.79
Working formDirect injection, turbocharged, with intercooler
Ground specific pressure (Kpa)65
Rotation speed (rpm)11.8
Climbing ability (%)70/35 °
Bucket digging force (kN)237
Rod digging force (kN)172
Travel speed (km/h)3.2/5.0
Main overflow set pressure (Mpa)31.4
Rotary hydraulic motor typeAxial piston motor ×1
Type of walking hydraulic motorVariable axial piston motor ×2
Maximum flow of main pump (l/min)2 x 288 + 30.2
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)32.4
Hydraulic crushing pipeline is standardno
Main pump typeVariable axial piston pump ×2+ gear pump ×1
Working Hydraulic Circuit (Mpa)34.3
Pilot Oil Circuit (MPa)3.9
Bucket cylinders - Number × diameter × stroke (mm)140 x 95
Bucket rod cylinders - Number × diameter × stroke (mm)170 x 115
Boom cylinders - Number × diameter × stroke (mm)146 x 100
Fuel Tank (L)630
Hydraulic Tank (L)180
Engine Oil changes (L)41
Coolant (L)32
Total transport length (mm)10970
Total transport width (mm)3190
Total transport height (mm)3230
Full cab height (mm)3140
Counterweight ground clearance (mm)1160
Minimum ground clearance (mm)500
Back end turning radius (mm)3320
Total track length (mm)4640
Track gauge (mm)2590
Track plate width (mm)600
Total track width (mm)3190
Track ground length (mm)3730
Maximum digging radius (mm)11100
Maximum digging depth (mm)7360
Maximum excavation height (mm)10250
Maximum unloading height (mm)7150
Bulldozer lift or depth (mm)No bulldozer
Dodging plate width × height (mm)No bulldozer
Maximum excavation radius of stop surface (mm)10890
Maximum effective digging depth (mm)7200
see more

Overview

No.1164526

Brand Name:

Hitachi

Model Number:

ZX330-3G

Year:

2011

Location:

Zhejiang China

Pub Date:
