Product Description
2020 Hitachi ZX330-5A hydraulic excavator available for immediate purchase in Zhejiang, China. This 33-ton class machine represents Hitachi's proven Dash-5A generation, engineered for demanding earthmoving and construction applications. Factory documentation and operational video available upon request.
- Model Year: 2020
- Manufacturer: Hitachi Construction Machinery
- Series: ZX330-5A
- Current Location: Zhejiang Province, China
- Availability: In-stock, ready for inspection
- Documentation: Photographs and video footage provided
The ZX330-5A features Hitachi's HIOS III hydraulic system for optimized fuel efficiency and cycle times. Suitable for general excavation, material handling, and site development projects. Machine condition can be verified through supplied media or arranged site visit. Export documentation and logistics support available for international buyers.
| Specifications | Value |
|---|---|
| No. | 1123095 |
| Tonnage (tons) | 33 |
| Working weight (kg) | 32700 |
| Bucket capacity (m³) | 1.45-1.62 |
| Boom length (mm) | 6400 |
| Rod length (mm) | 3200 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu GH-6HK1XKSA-01 |
| Rated power (kw/rpm) | 190/1900 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 115 x 125 |
| Maximum torque (N.m) | 1037/1500 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.790 |
| Working form | 4 stroke, water cooled, electrically controlled direct injection, turbocharged, intercooled |
| Ground specific pressure (Kpa) | 66 |
| Rotation speed (rpm) | 10.7 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 246 |
| Rod digging force (kN) | 185 |
| Maximum tractive force (kN) | 298 |
| Travel speed (km/h) | 3.2-5.0 |
| Turning torque (Nm) | 120 |
| Rotary hydraulic motor type | 1 swashplate plunger motor |
| Type of walking hydraulic motor | 2 variable swash plate plunger motor |
| Maximum flow of main pump (l/min) | 2 x 288 |
| Traveling Hydraulic Circuit (Mpa) | 34.8 |
| Rotary Hydraulic Circuit (Mpa) | 32.4 |
| Main pump type | 2 variable axial piston pumps |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Pilot pump flow (L/min) | 30.2 |
| Pilot pump type | 1 gear pump |
| Fuel Tank (L) | 630 |
| Hydraulic Tank (L) | 180 |
| Engine Oil changes (L) | 41 |
| Coolant (L) | 35 |
| Hydraulic System (L) | 340 |
| Total transport length (mm) | 11220 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3270 |
| Full cab height (mm) | 3160 |
| Counterweight ground clearance (mm) | 1160 |
| Minimum ground clearance (mm) | 500 |
| Minimum turning radius of front working device (mm) | 4610 |
| Back end turning radius (mm) | 3590 |
| Onboard width (mm) | 2990 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 3730 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 11100 |
| Maximum digging depth (mm) | 7380 |
| Maximum excavation height (mm) | 10360 |
| Maximum unloading height (mm) | 7240 |
| Maximum vertical digging depth (mm) | 6420 |
| Maximum excavation radius of stop surface (mm) | 10890 |
