Product Description
This 2021 Hitachi ZX350H-5A hydraulic excavator is available from Zhejiang, China. The machine features original factory paint and presents in excellent overall condition with strong operational performance. Key components including the undercarriage and bucket show minimal wear, reflecting careful use and proper maintenance throughout its service life.
The ZX350H-5A is built on Hitachi's proven hydraulic excavator platform, offering reliable performance for medium to heavy-duty earthmoving applications. This unit's well-maintained condition makes it suitable for contractors seeking dependable equipment without the premium of new machinery.
- Year: 2021
- Make: Hitachi
- Model: ZX350H-5A
- Location: Zhejiang, China
- Condition: Used, excellent overall state
- Paint: Original factory finish
- Undercarriage: Approximately 90% remaining
Inspection welcomed. Competitive pricing available for qualified buyers.
| Specifications | Value |
|---|---|
| No. | 1153046 |
| Tonnage (tons) | 34 |
| Working weight (kg) | 34000 |
| Bucket capacity (m³) | 1.4-1.8 |
| Boom length (mm) | 6400 |
| Rod length (mm) | 2670 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu GH-6HK1X |
| Rated power (kw/rpm) | 190 |
| Cylinder diameter × stroke (mm) | 115 mm x 125 mm |
| Maximum torque (N.m) | 1 037 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.790 |
| Ground specific pressure (Kpa) | 65 |
| Rotation speed (rpm) | 10.7 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 214-246 |
| Rod digging force (kN) | 213-222 |
| Maximum tractive force (kN) | 298 |
| Travel speed (km/h) | 0 ~ 5.0 |
| Rotary hydraulic motor type | 1 axial plunger motor |
| Type of walking hydraulic motor | 2 variable axial piston motors |
| Maximum flow of main pump (l/min) | 2 x 288 |
| Traveling Hydraulic Circuit (Mpa) | 34.8 |
| Rotary Hydraulic Circuit (Mpa) | 32.4 |
| Main pump type | 2 variable axial piston pumps |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 140 x 95 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 170 x 115 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 145 x 100 |
| Pilot pump type | 1 gear pump |
| Fuel Tank (L) | 630 |
| Hydraulic Tank (L) | 180 |
| Engine Oil changes (L) | 41 |
| Coolant (L) | 35 |
| Maximum digging radius (mm) | 10570 |
| Maximum digging depth (mm) | 6840 |
| Maximum excavation height (mm) | 9990 |
| Maximum unloading height (mm) | 6940 |
| Maximum vertical digging depth (mm) | 5510 |
| Maximum excavation radius of stop surface (mm) | 10360 |
| Number of wheels (single side) (each) | 7 : ZX330-5A/ZX350H-5A |
| Number of track plates (single side) (PCS) | 45 : ZX330-5A/ZX350H-5A |
