Product Description
Engineered with precision in Hefei, this 2011 Hitachi ZX60 compact excavator delivers 40.5kW of reliable ISUZU CC-4JG1 power through a sophisticated hydraulic system designed for demanding job sites. Dual variable piston pumps and axial piston rotary motor provide exceptional control, with main overflow pressure rated at 24.5 MPa ensuring consistent performance across all functions. Operating at 5,850kg working weight, this 6-ton machine achieves a maximum digging depth of 3,850mm and reaches 6,250mm radius, while maintaining ground-specific pressure of just 33 kPa for minimal surface disturbance.
Hydraulic efficiency defines this model's technical advantage. Bucket digging force reaches 41.4kN, supported by variable swash plate plunger travel motors and a 61-liter hydraulic reservoir. The water-cooled 4-cylinder engine delivers 3.059L displacement with direct injection, paired with dual-speed travel capability (2.5/4.5 km/h) and 9.3 rpm rotation speed. Compact transport dimensions of 6,060mm length × 2,060mm width make mobilization straightforward, while 70% grading ability and 620mm counterweight clearance ensure versatility across varied terrain. Currently located in Wenzhou, Zhejiang, this joint-venture manufactured unit
| Specifications | Value |
|---|---|
| No. | 1034020 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
