Product Description
Proven through nearly a decade of reliable operation, this 2015 Hitachi ZX60 mini excavator demonstrates the exceptional build quality that defines Japanese engineering. Operating at 5,850 kg with a robust ISUZU CC-4JG1 engine delivering 40.5 kW, this compact workhorse has consistently delivered performance in demanding jobsites across Jiangsu province. Its 0.22 m³ bucket capacity and impressive 41.4 kN bucket digging force provide serious productivity in a machine that's stood the test of time.
- Maximum digging depth of 3,850 mm with 6,250 mm reach radius
- Dual variable piston pumps ensuring hydraulic reliability
- Water-cooled 4-cylinder engine with proven longevity
- 70% climbing ability for challenging terrain navigation
- Compact 2,060 mm transport width for versatile site access
Currently located in Lianyungang, this joint-venture manufactured machine represents a smart investment in equipment with a documented track record. Built in Hefei with quality components including axial piston motors and variable swash plate technology, it continues to offer dependable performance for contractors seeking value without compromising capability.
| Specifications | Value |
|---|---|
| No. | 1034036 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
