Product Description
Engineered with precision hydraulics and robust mechanical systems, this 2015 Hitachi ZX60-5G represents proven compact excavator technology. Operating at 5,960 kg working weight with a 0.24 m³ bucket capacity, this 6-ton machine delivers consistent performance across demanding jobsites. The Yanmar 4TNV98-AVHBW engine generates 42.4 kW at 2100 rpm with 236 N·m maximum torque, providing reliable power through a water-cooled, four-stroke direct injection system.
Hydraulic architecture features three variable axial piston pumps operating at 24.5 MPa working pressure, supported by a 93-liter hydraulic system capacity. Performance specifications include 6,250 mm maximum digging radius, 3,850 mm digging depth, and 38.5 kN maximum tractive force. The machine achieves 70% (35°) climbing ability with 9.1 rpm rotation speed, backed by dual variable axial piston travel motors and single axial plunger rotation motor.
Compact dimensions—6,060 mm length, 2,060 mm width, 2,085 mm transport height—facilitate maneuverability in confined spaces while maintaining 310 mm minimum ground clearance. Currently located in Guangxi, this joint venture-manufactured unit from Hefei exemplifies Hitachi's engineering standards for the Chinese cons
| Specifications | Value |
|---|---|
| No. | 999772 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.24 |
| Country of origin | Hefei (Capital of Anhui Province) |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98-AVHBW |
| Rated power (kw/rpm) | 42.4/2100 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Maximum torque (N.m) | 236 |
| Number of cylinders (PCS) | 4 |
| Working form | Four-stroke, water-cooled, direct injection |
| Rotation speed (rpm) | 9.1 |
| Climbing ability (%) | 70% (35°) |
| Maximum tractive force (kN) | 38.5 |
| Travel speed (km/h) | 0-4.5/0-2.5 |
| Turning torque (Nm) | 10 |
| Rotary hydraulic motor type | 1 axial plunger motor |
| Type of walking hydraulic motor | 2 variable axial piston motors |
| Traveling Hydraulic Circuit (Mpa) | 24.5 |
| Rotary Hydraulic Circuit (Mpa) | 17.6 |
| Main pump type | 3 variable axial piston pumps |
| Working Hydraulic Circuit (Mpa) | 24.5 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 60 |
| Coolant (L) | 8 |
| Hydraulic System (L) | 93 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2085 |
| Full cab height (mm) | 2475 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Onboard width (mm) | 2060 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3440 |
| Dodging plate width × height (mm) | 200 x 400 |
| Maximum excavation radius of stop surface (mm) | 6130 |
