Product Description
This 2026 Hitachi ZX65USB-3F compact excavator, manufactured in May 2026, presents an exceptional opportunity with only 72 actual operating hours recorded. Currently located in Anhui, China, this machine remains under Hitachi's factory warranty, providing buyers with additional peace of mind and manufacturer support.
The ZX65USB-3F is a zero-tail-swing model engineered for confined jobsites where space constraints demand precision maneuvering. With minimal use since delivery, this unit offers near-new condition performance at a competitive price point.
- Actual hours: 72
- Manufacturing date: May 2026
- Hitachi factory warranty active
- Zero-tail-swing design for tight spaces
- Current location: Anhui Province, China
The owner is divesting due to capital reallocation toward other business ventures. This low-hour machine represents a sound investment for contractors seeking reliable compact excavation equipment with verifiable service history.
| Specifications | Value |
|---|---|
| No. | 1157356 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 6350 |
| Bucket capacity (m³) | 0.27 |
| Boom length (mm) | 2970 |
| Rod length (mm) | 1500 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 4TNV98 |
| Rated power (kw/rpm) | 40.5/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Maximum torque (N.m) | 243/1000 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.318 |
| Working form | Direct injection type |
| Ground specific pressure (Kpa) | 36 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 58%(30 degrees) |
| Bucket digging force (kN) | 41.1 |
| Rod digging force (kN) | 31.1 |
| Maximum tractive force (kN) | 39.8 |
| Travel speed (km/h) | 4.2/2.4 |
| Turning torque (Nm) | 11 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable axial piston motor ×2 |
| Maximum flow of main pump (l/min) | 144 |
| Traveling Hydraulic Circuit (Mpa) | 25.7 |
| Rotary Hydraulic Circuit (Mpa) | 19.6 |
| Main pump type | Variable axial piston pump ×1+ gear pump ×1 |
| Working Hydraulic Circuit (Mpa) | 24.5 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Pilot pump flow (L/min) | 10.4 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-80 x 570 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-90 x 770 |
| Boom cylinders - Number × diameter × stroke (mm) | 1-110 x 785 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 100 |
| Engine Oil changes (L) | 11.9 |
| Coolant (L) | 6.5 |
| Hydraulic System (L) | 127.5 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 2000 |
| Total transport height (mm) | 2550 |
| Full cab height (mm) | 2550 |
| Counterweight ground clearance (mm) | 615 |
| Minimum ground clearance (mm) | 330 |
| Minimum turning radius of front working device (mm) | 2470 |
| Back end turning radius (mm) | 1390 |
| Onboard width (mm) | 2000 |
| Total track length (mm) | 2450 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Maximum digging radius (mm) | 6230 |
| Maximum digging depth (mm) | 3770 |
| Maximum excavation height (mm) | 5960 |
| Maximum unloading height (mm) | 4170 |
| Maximum vertical digging depth (mm) | 3050 |
| Bulldozer lift or depth (mm) | 445/390 |
| Dodging plate width × height (mm) | 2000 x 415 |
| Maximum excavation radius of stop surface (mm) | 6090 |
| Boom turning Angle (left/right °) | Left 65/ right 60 |
| Boom offset (left/right °) | Left 720/ Right 795 |
Overview
No.1157356
Brand Name：
HitachiModel Number：
ZX65USB-3FYear：
2026
Location：
Anhui China
Pub Date：
