2019 Hyundai

1/4
Buy Hyundai Used Excavator / 1
Buy Hyundai Used Excavator / 2
Buy Hyundai Used Excavator / 3
Buy Hyundai Used Excavator / 4

Product Description

This 2019 Hyundai excavator with integrated hydraulic breaker attachment offers proven performance for demolition and rock-breaking applications. Originally deployed in Hunan, China, this machine combines Hyundai's reliable engineering with the versatility of hammer functionality, making it suitable for construction, quarrying, and infrastructure projects.

Key features include:

  • Factory-installed hydraulic hammer system
  • 2019 model year with operational history in Chinese market
  • Integrated breaker attachment for immediate deployment
  • Hyundai drivetrain and hydraulic components
  • Currently located in Hunan Province, China

This unit is available for immediate export at competitive pricing. The hydraulic hammer configuration expands operational capabilities beyond standard excavation work. Ideal for contractors seeking cost-effective used equipment with demolition capacity. Inspection reports and shipping arrangements available upon request.

SpecificationsValue
No.1163176
Tonnage (tons)11
Bucket capacity (m³)0.45m3
Boom length (mm)4300mm
Rod length (mm)2260mm
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeMITSUBISHI 4FRC
Rated power (kw/rpm)99(74) / 2000
Cylinder diameter × stroke (mm)102 (4.02) x 130 (5.12)
Maximum torque (N.m)43.5(315) / 1350
Displacement (L)4.2
Working form4 cylinder 4 stroke water cooled direct injection engine
Climbing ability (%)70
Travel speed (km/h)5.5 km/h (3.4 mph) / 3.4 km/h (2.1 mph)
Maximum flow of main pump (l/min)2×112 (2×29.6)
Traveling Hydraulic Circuit (Mpa)330
Rotary Hydraulic Circuit (Mpa)240
Main pump typeTwo variable plunger pump
Working Hydraulic Circuit (Mpa)330
Bucket cylinders - Number × diameter × stroke (mm)1-95 x 65 x 855
Bucket rod cylinders - Number × diameter × stroke (mm)1-110 x 75 x 1070
Boom cylinders - Number × diameter × stroke (mm)2-95 x 70 x 1015
Fuel Tank (L)250
Hydraulic Tank (L)100
Engine Oil changes (L)17.5
Coolant (L)24
Hydraulic System (L)210
Full cab height (mm)2800
Counterweight ground clearance (mm)900
Back end turning radius (mm)2380mm
Total track length (mm)7270
Total track width (mm)2490
Maximum digging radius (mm)7740mm
Maximum digging depth (mm)5090mm
Maximum excavation height (mm)8070mm
Maximum unloading height (mm)5710mm
Maximum vertical digging depth (mm)4430mm
Maximum excavation radius of stop surface (mm)7610mm
see more
