2018 Hyundai R110VS

1/9
Buy Hyundai R110VS Used Excavator / 1
Buy Hyundai R110VS Used Excavator / 2
Buy Hyundai R110VS Used Excavator / 3
Buy Hyundai R110VS Used Excavator / 4
Buy Hyundai R110VS Used Excavator / 5
Buy Hyundai R110VS Used Excavator / 6
Buy Hyundai R110VS Used Excavator / 7
Buy Hyundai R110VS Used Excavator / 8
Buy Hyundai R110VS Used Excavator / 9

Product Description

This 2018 Hyundai R110VS excavator represents a solid investment for contractors seeking reliable mid-size performance. Currently located in Yunnan, China, this machine has been maintained in excellent working condition and is priced competitively for immediate acquisition.

The R110VS is designed for versatility across construction, mining, and infrastructure projects. Its compact dimensions enable operation in space-constrained environments while delivering the power needed for demanding excavation tasks.

  • Year of Manufacture: 2018
  • Model: Hyundai R110VS
  • Current Location: Yunnan Province, China
  • Condition: Well-maintained with verified operational status
  • Availability: Ready for immediate inspection and purchase

This unit offers an opportunity to expand your fleet with proven Hyundai engineering at an accessible price point. Suitable for buyers seeking dependable equipment with transparent service history.

SpecificationsValue
No.1162954
Tonnage (tons)11
Working weight (kg)11200
Bucket capacity (m³)0.45
Boom length (mm)4300
Rod length (mm)2260
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeMitsubishi D04FRC-TAA
Rated power (kw/rpm)74/2000
Cooling modewater-cooling
Cylinder diameter × stroke (mm)102 x 130
Maximum torque (N.m)44.4 / 1350
Number of cylinders (PCS)4
Displacement (L)4.249
Working form4 cylinder, 4 stroke, water cooled
Rotation speed (rpm)13
Climbing ability (%)70
Travel speed (km/h)5.5 / 3.4
Maximum flow of main pump (l/min)2 x 112
Traveling Hydraulic Circuit (Mpa)330
Rotary Hydraulic Circuit (Mpa)240
Main pump typeTwo variable plunger pump
Pilot Oil Circuit (MPa)35
Bucket cylinders - Number × diameter × stroke (mm)1 - ø 95 x ø 65 x 855
Bucket rod cylinders - Number × diameter × stroke (mm)1 - ø 110 x ø 75 x 1070
Boom cylinders - Number × diameter × stroke (mm)2 - ø 95 x ø 70 x 1015
Pilot pump typeGear pump
Fuel Tank (L)250
Hydraulic Tank (L)100
Engine Oil changes (L)17.5
Coolant (L)24
Hydraulic System (L)210
Total transport length (mm)7270
Total transport width (mm)2490
Total transport height (mm)2800
Full cab height (mm)2800
Counterweight ground clearance (mm)900
Minimum turning radius of front working device (mm)2380
Back end turning radius (mm)2130
Onboard width (mm)2475
Track plate width (mm)500
Number of sprockets (single side) (each)1
Number of wheels (single side) (each)6
Number of track plates (single side) (PCS)46
Maximum digging radius (mm)7740
Maximum digging depth (mm)5090
Maximum excavation height (mm)8070
Maximum unloading height (mm)5710
Maximum vertical digging depth (mm)4430
Maximum excavation radius of stop surface (mm)7610
see more

Overview

No.1162954

Brand Name:

Hyundai

Model Number:

R110VS

Year:

2018

Location:

Yunnan China

Pub Date:
