Product Description
Built for the long haul, this 2021 Hyundai R205VS excavator demonstrates exceptional durability through its robust construction and proven Cummins QSB7 engine. Operating at 125kW rated power with impressive 670 N.m torque, this 20-ton workhorse delivers consistent performance across demanding jobsites. With just five years in service, the machine showcases Hyundai's joint venture engineering excellence and build quality that stands the test of time.
Performance credentials include a 9,720mm maximum digging radius, 6,550mm digging depth, and 0.9m³ bucket capacity—specifications that have proven reliable day after day. Dual variable plunger pumps push 2×222 L/min flow for responsive hydraulics, while the 70% climbing ability tackles challenging terrain with confidence. Currently located in Jiangsu Suqian, this R205VS represents dependable productivity backed by a manufacturer known for longevity.
- 20-ton operating weight with proven track record
- Cummins QSB7 engine: 125kW power, 6.7L displacement
- 9,720mm reach, 6,550mm digging depth
- Dual variable pumps: 2×222 L/min hydraulic flow
- 340L fuel capacity for extended operation
| Specifications | Value |
|---|---|
| No. | 1029348 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 19900 |
| Bucket capacity (m³) | 0.9 |
| Boom length (mm) | 5650 |
| Rod length (mm) | 2700 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins QSB7 |
| Rated power (kw/rpm) | 125/1900 |
| Cylinder diameter × stroke (mm) | 107*124 |
| Maximum torque (N.m) | 67/1500 |
| Displacement (L) | 6.7 |
| Rotation speed (rpm) | 11.2 |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.9/3.8 |
| Maximum flow of main pump (l/min) | 2*222 |
| Main pump type | Two variable plunger pump |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 180 |
| Engine Oil changes (L) | 24 |
| Coolant (L) | 35 |
| Hydraulic System (L) | 270 |
| Total transport length (mm) | 9500 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2970 |
| Full cab height (mm) | 3000 |
| Counterweight ground clearance (mm) | 1060 |
| Minimum turning radius of front working device (mm) | 3470 |
| Back end turning radius (mm) | 2830 |
| Onboard width (mm) | 2740 |
| Total track length (mm) | 4160 |
| Track ground length (mm) | 3360 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 46 |
| Maximum digging radius (mm) | 9720 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9640 |
| Maximum unloading height (mm) | 6830 |
| Maximum vertical digging depth (mm) | 5920 |
| Maximum excavation radius of stop surface (mm) | 9550 |
