Product Description
This 2022 Hyundai R205VS crawler excavator offers reliable performance for mid-range excavation and material handling applications. With approximately two years of operational history, this machine represents a cost-effective entry point for contractors seeking proven Hyundai engineering without the premium of new equipment.
Currently located in Zhejiang, China, this unit is available at 195,000 RMB. The R205VS is designed for versatility across construction, demolition, and earthmoving projects, featuring a robust undercarriage and hydraulic system suitable for demanding job sites.
- Year of Manufacture: 2022
- Model: Hyundai R205VS
- Location: Zhejiang Province, China
- Price: 195,000 RMB
- Machine Type: Crawler Excavator
Suitable for buyers seeking a late-model excavator with minimal wear. Inspection recommended prior to purchase. Export documentation and logistics can be arranged upon request.
| Specifications | Value |
|---|---|
| No. | 1144994 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 19900 |
| Bucket capacity (m³) | 0.9 |
| Boom length (mm) | 5650 |
| Rod length (mm) | 2700 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins QSB7 |
| Rated power (kw/rpm) | 125/1900 |
| Cylinder diameter × stroke (mm) | 107*124 |
| Maximum torque (N.m) | 67/1500 |
| Displacement (L) | 6.7 |
| Rotation speed (rpm) | 11.2 |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.9/3.8 |
| Maximum flow of main pump (l/min) | 2*222 |
| Main pump type | Two variable plunger pump |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 180 |
| Engine Oil changes (L) | 24 |
| Coolant (L) | 35 |
| Hydraulic System (L) | 270 |
| Total transport length (mm) | 9500 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2970 |
| Full cab height (mm) | 3000 |
| Counterweight ground clearance (mm) | 1060 |
| Minimum turning radius of front working device (mm) | 3470 |
| Back end turning radius (mm) | 2830 |
| Onboard width (mm) | 2740 |
| Total track length (mm) | 4160 |
| Track ground length (mm) | 3360 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 46 |
| Maximum digging radius (mm) | 9720 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9640 |
| Maximum unloading height (mm) | 6830 |
| Maximum vertical digging depth (mm) | 5920 |
| Maximum excavation radius of stop surface (mm) | 9550 |
