2020 Hyundai R265LC-7

1/9
Buy Hyundai R265LC-7 Used Excavator / 1
Buy Hyundai R265LC-7 Used Excavator / 2
Buy Hyundai R265LC-7 Used Excavator / 3
Buy Hyundai R265LC-7 Used Excavator / 4
Buy Hyundai R265LC-7 Used Excavator / 5
Buy Hyundai R265LC-7 Used Excavator / 6
Buy Hyundai R265LC-7 Used Excavator / 7
Buy Hyundai R265LC-7 Used Excavator / 8
Buy Hyundai R265LC-7 Used Excavator / 9

Product Description

Well-maintained 2020 Hyundai R265LC-7 excavator available in Beijing, China. This single-owner machine features original factory paint and has been consistently serviced throughout its operational life. The excavator comes from a completed project site and is ready for immediate deployment.

  • Year: 2020
  • Model: Hyundai R265LC-7
  • Condition: Used, original paint
  • Ownership: Single owner
  • Location: Beijing, China
  • Status: Available for inspection and test operation

This R265LC-7 represents a solid investment for contractors seeking reliable excavation capacity. The machine's maintenance history and clean condition reflect careful operational practices. Complete documentation, photos, and video available upon request. Suitable for earthmoving, construction, and general excavation applications.

SpecificationsValue
No.1164769
Tonnage (tons)26
Working weight (kg)25200
Bucket capacity (m³)1.08
Boom length (mm)5850
Rod length (mm)3050
Country of originJiangsu (Province)
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeCummins B5.9-C
Rated power (kw/rpm)133/2000
Cooling modewater-cooling
Cylinder diameter × stroke (mm)102 x 120
Number of cylinders (PCS)6
Displacement (L)5880
Ground specific pressure (Kpa)51
Rotation speed (rpm)12.6
Climbing ability (%)70/35 °
Bucket digging force (kN)178.5
Rod digging force (kN)118.7
Travel speed (km/h)3.5-5.5
Maximum flow of main pump (l/min)2 x 224
Traveling Hydraulic Circuit (Mpa)330
Rotary Hydraulic Circuit (Mpa)275
Hydraulic crushing pipeline is standardno
Main pump type2× variable axial piston pump + gear pump
Working Hydraulic Circuit (Mpa)330
Pilot Oil Circuit (MPa)35
Bucket cylinders - Number × diameter × stroke (mm)135 * 90 * 1185
Bucket rod cylinders - Number × diameter × stroke (mm)150 * 110 * 1620
Boom cylinders - Number × diameter × stroke (mm)140 * 95 * 1345
Fuel Tank (L)340
Hydraulic Tank (L)190
Engine Oil changes (L)24
Coolant (L)45
Hydraulic System (L)300
Total transport length (mm)9920
Total transport width (mm)3180
Total transport height (mm)3220
Full cab height (mm)2990
Counterweight ground clearance (mm)1115
Minimum ground clearance (mm)480
Back end turning radius (mm)2965
Total track length (mm)4640
Track gauge (mm)2580
Track plate width (mm)600
Total track width (mm)3180
Track ground length (mm)3830
Maximum digging radius (mm)10360
Maximum digging depth (mm)7000
Maximum excavation height (mm)9670
Maximum unloading height (mm)6630
Maximum vertical digging depth (mm)6150
Bulldozer lift or depth (mm)There is no
Dodging plate width × height (mm)There is no
Maximum excavation radius of stop surface (mm)10190
Maximum effective digging depth (mm)6380
see more

Overview

No.1164769

Brand Name:

Hyundai

Model Number:

R265LC-7

Year:

2020

Location:

Peking China

Pub Date:
