Product Description
This 2012 Hyundai R60-7 compact excavator offers reliable performance for construction and utility applications. Currently located in Sichuan, China, this 6-tonne class machine represents a proven workhorse in Hyundai's mini excavator lineup.
Equipped with a dependable Yanmar diesel engine, this unit delivers the fuel efficiency and durability expected from Japanese power technology. The hydraulic system provides smooth operation and precise control for demanding job site tasks including trenching, grading, and material handling.
- Year of Manufacture: 2012
- Model: Hyundai R60-7
- Engine: Yanmar diesel
- Current Location: Sichuan Province, China
- Machine Class: 6-tonne compact excavator
The R60-7 is well-suited for urban construction, landscaping, and light excavation work where maneuverability and compact dimensions are essential. Available for inspection in Sichuan.
| Specifications | Value |
|---|---|
| No. | 1098796 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.06-0.21 |
| Country of origin | Peking |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar Yanma 4TNV94L |
| Rated power (kw/rpm) | 40/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Rotation speed (rpm) | 9.6 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 37.7 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.2-4.0 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | 2× variable axial piston pump + gear pump |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 70 |
| Total transport length (mm) | 5900 |
| Total transport width (mm) | 1920 |
| Total transport height (mm) | 2550 |
| Full cab height (mm) | 2550 |
| Minimum ground clearance (mm) | 380 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1520 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 1920 |
| Track ground length (mm) | 1990 |
| Maximum digging radius (mm) | 6150 |
| Maximum digging depth (mm) | 3820 |
| Maximum excavation height (mm) | 5780 |
| Maximum unloading height (mm) | 4050 |
| Maximum vertical digging depth (mm) | 3200 |
| Dodging plate width × height (mm) | 1920 x 350 |
| Maximum excavation radius of stop surface (mm) | 6010 |
| Maximum effective digging depth (mm) | 3420 |
