Product Description
Available now in Hunan, China: a 2017 John Deere E330LC hydraulic excavator, a 330-class crawler machine built for sustained production work in earthmoving, quarrying and general civil construction. This unit has been in regular service and remains operational, ready for physical inspection and site deployment.
Key details:
- Year of manufacture: 2017
- Brand and model: John Deere E330LC
- Machine type: tracked hydraulic excavator, 330 class
- Standard configuration: diesel engine, enclosed cab, standard boom and arm
- Location: Hunan Province, China — inspection by appointment
- Indicative price: 150,000+ RMB, ex-works
Operating hours, undercarriage condition and service history can be supplied on request. Loading, inland transport and export documentation can be coordinated for overseas buyers. Enquiries from serious trade buyers are welcome.
| Specifications | Value |
|---|---|
| No. | 1157487 |
| Tonnage (tons) | 33 |
| Working weight (kg) | 34200 - 36600 |
| Bucket capacity (m³) | 1.6 |
| Boom length (mm) | 6450 |
| Rod length (mm) | 3200 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 204/2000 |
| Maximum torque (N.m) | 1310/1400 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 9.0 |
| Working form | |
| Ground specific pressure (Kpa) | 63.4 |
| Rotation speed (rpm) | 9.6 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 218 |
| Rod digging force (kN) | 180-196 |
| Maximum tractive force (kN) | 297 |
| Travel speed (km/h) | 5.2/3.1 |
| Turning torque (Nm) | 106.3 |
| Maximum flow of main pump (l/min) | |
| Traveling Hydraulic Circuit (Mpa) | 35.3 |
| Rotary Hydraulic Circuit (Mpa) | 27.4 |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 32.4 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Pilot pump flow (L/min) | 30 x 1 |
| Fuel Tank (L) | 600 |
| Hydraulic Tank (L) | 259 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 33 |
| Hydraulic System (L) | 484 |
| Total transport length (mm) | 11130 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3510 |
| Full cab height (mm) | 3180 |
| Counterweight ground clearance (mm) | 1170 |
| Minimum ground clearance (mm) | 480 |
| Minimum turning radius of front working device (mm) | 4370 |
| Back end turning radius (mm) | 3400 |
| Onboard width (mm) | 2990 |
| Total track length (mm) | 4950 |
| Track gauge (mm) | 2600 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3200 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 11250 |
| Maximum digging depth (mm) | 7660 |
| Maximum excavation height (mm) | 10470 |
| Maximum unloading height (mm) | 7140 |
| Maximum vertical digging depth (mm) | 6490 |
| Maximum excavation radius of stop surface (mm) | 10990 |
