Product Description
Built for the long haul, this 2014 Kobelco SK130 excavator demonstrates exceptional durability through nearly a decade of proven performance. Engineered in Japan with a robust Mitsubishi D04FR engine delivering 74kW at 2000rpm, this 13-ton workhorse combines reliability with impressive operational capabilities. Currently located in Luzhou, Sichuan, this machine features a 0.52m³ backhoe bucket and maintains excellent digging force at 90.1kN, making it ideal for medium-duty excavation projects.
- Maximum digging reach: 8,340mm with 5,520mm depth capability
- Compact transport dimensions: 7,790mm × 2,490mm × 2,710mm
- Superior climbing ability: 70% gradient (35°)
- Dual travel speeds: 3.4/5.6 km/h for versatile site mobility
- Generous fuel capacity: 275L tank for extended operation
- Tight swing radius: 2,190mm rear clearance for confined spaces
With a working weight of 12,800kg and proven joint-venture manufacturing quality, this SK130 represents a cost-effective solution for contractors seeking dependable equipment with established performance credentials. A true testament to Kobelco's engineering excellence.
| Specifications | Value |
|---|---|
| No. | 1028132 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12800 |
| Bucket capacity (m³) | 0.52 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi D04FR |
| Rated power (kw/rpm) | 74/2000 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 90.1 |
| Travel speed (km/h) | 3.4/5.6 |
| Fuel Tank (L) | 275 |
| Hydraulic Tank (L) | 101 |
| Total transport length (mm) | 7790 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2710 |
| Full cab height (mm) | 2870 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2190 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 2870 |
| Track plate width (mm) | 500/600/700 |
| Maximum digging radius (mm) | 8340 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8500 |
| Maximum unloading height (mm) | 6090 |
| Maximum vertical digging depth (mm) | 4880 |
| Dodging plate width × height (mm) | 500 |
| Maximum excavation radius of stop surface (mm) | 8190 |
| Maximum effective digging depth (mm) | 5290 |
