Product Description
Available now in Guizhou, this 2019 Kobelco SK130 excavator eliminates factory wait times and delivers immediate productivity to your job site. Powered by a reliable Mitsubishi D04FR engine generating 74kW at 2000rpm, this 13-ton workhorse combines Japanese engineering precision with proven joint-venture manufacturing quality. Skip months of procurement delays—this machine is ready for fast deployment across Southwest China and beyond.
- Operating Weight: 12,800 kg with 0.52 m³ bucket capacity
- Digging Performance: 8,340 mm maximum reach, 5,520 mm depth, 90.1 kN bucket force
- Mobility: 70% grading ability, dual travel speeds (3.4/5.6 km/h)
- Compact Transport: 7,790 mm length × 2,490 mm width fits standard logistics
- Extended Operation: 275L fuel tank, 101L hydraulic reservoir
Positioned in Guizhou for rapid mobilization, this SK130 offers immediate ROI without production lead times. Inspect, approve, and deploy—your equipment solution starts today, not next quarter.
| Specifications | Value |
|---|---|
| No. | 1019132 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12800 |
| Bucket capacity (m³) | 0.52 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi D04FR |
| Rated power (kw/rpm) | 74/2000 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 90.1 |
| Travel speed (km/h) | 3.4/5.6 |
| Fuel Tank (L) | 275 |
| Hydraulic Tank (L) | 101 |
| Total transport length (mm) | 7790 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2710 |
| Full cab height (mm) | 2870 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2190 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 2870 |
| Track plate width (mm) | 500/600/700 |
| Maximum digging radius (mm) | 8340 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8500 |
| Maximum unloading height (mm) | 6090 |
| Maximum vertical digging depth (mm) | 4880 |
| Dodging plate width × height (mm) | 500 |
| Maximum excavation radius of stop surface (mm) | 8190 |
| Maximum effective digging depth (mm) | 5290 |
