Product Description
Built for operators who demand precision and control, the 2021 Kobelco SK130 delivers a confident working experience across demanding job sites. Powered by a Mitsubishi D04FR engine producing 74 kW at 2000 rpm, this 13-ton excavator balances raw digging performance with refined handling — making it a dependable choice for contractors in earthmoving, trenching, and site preparation work.
From the cab, operators benefit from the visibility and ergonomic layout characteristic of Kobelco's Japanese-engineered design philosophy. A low back-end turning radius of 2,190 mm supports tight-space maneuverability without sacrificing stability, while a 70% gradeability rating keeps performance consistent on uneven terrain.
- Bucket digging force: 90.1 kN for reliable penetration in compacted ground
- Maximum digging depth: 5,520 mm — suited for utility trenching and foundation work
- Maximum digging radius: 8,340 mm for extended horizontal reach
- Travel speed: up to 5.6 km/h for efficient site repositioning
- Fuel tank capacity: 275 L for extended operation between refuels
- Track plate width options: 500 / 600 / 700 mm to match ground conditions
- Currently available in Zhejiang, China — ready for inspection and export
| Specifications | Value |
|---|---|
| No. | 1041404 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12800 |
| Bucket capacity (m³) | 0.52 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi D04FR |
| Rated power (kw/rpm) | 74/2000 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 90.1 |
| Travel speed (km/h) | 3.4/5.6 |
| Fuel Tank (L) | 275 |
| Hydraulic Tank (L) | 101 |
| Total transport length (mm) | 7790 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2710 |
| Full cab height (mm) | 2870 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2190 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 2870 |
| Track plate width (mm) | 500/600/700 |
| Maximum digging radius (mm) | 8340 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8500 |
| Maximum unloading height (mm) | 6090 |
| Maximum vertical digging depth (mm) | 4880 |
| Dodging plate width × height (mm) | 500 |
| Maximum excavation radius of stop surface (mm) | 8190 |
| Maximum effective digging depth (mm) | 5290 |
