Product Description
Built for demanding excavation work, this 2016 Kobelco SK200 delivers 20-ton performance with proven Mitsubishi 6D34-TLU2D power. Currently located in Dezhou, Shandong, this machine arrives site-ready with 110kW rated output and turbocharged capabilities that push bucket digging force to 157kN when needed. Equipped with a 0.8m³ backhoe bucket and dual-speed travel system (4.0-6.0 km/h), it handles everything from foundation digging to material loading with industrial efficiency.
- Mitsubishi engine with water-cooled, turbocharged intercooling system
- Supercharged digging force: 157kN bucket, 107kN arm
- Double variable displacement axial piston pumps for responsive hydraulics
- 70% climbing ability with 45Kpa ground pressure (600mm tracks)
- 340L fuel capacity for extended operating shifts
- 11rpm rotation speed for efficient cycle times
Joint venture construction ensures reliable components throughout. This SK200 combines proven Japanese engineering with practical specifications that contractors depend on daily. Ready for demolition, grading, trenching, or general earthmoving across your project site.
| Specifications | Value |
|---|---|
| No. | 1030987 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20000 |
| Bucket capacity (m³) | 0.8 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi 6D34-TLU2D |
| Rated power (kw/rpm) | 110/2000 |
| Cooling mode | water-cooling |
| Working form | Water-cooled, four-stroke, six-cylinder, direct injection, turbocharged, built-in intercooling |
| Ground specific pressure (Kpa) | 45; 35 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 143; Supercharged state: 157 |
| Rod digging force (kN) | 97.1; Supercharged state: 107 |
| Travel speed (km/h) | 1 speed: 4.0 2 speed :6.0 |
| Main overflow set pressure (Mpa) | 34.3; Supercharged state: 37.8 |
| Main pump type | Double variable displacement axial piston pump pilot gear pump |
| Fuel Tank (L) | 340 |
| Track plate width (mm) | 600; 800 |
