2018 Kobelco SK495D

1/8
Buy Kobelco SK495D Used Excavator / 1
Buy Kobelco SK495D Used Excavator / 2
Buy Kobelco SK495D Used Excavator / 3
Buy Kobelco SK495D Used Excavator / 4
Buy Kobelco SK495D Used Excavator / 5
Buy Kobelco SK495D Used Excavator / 6
Buy Kobelco SK495D Used Excavator / 7
Buy Kobelco SK495D Used Excavator / 8

Product Description

This 2018 Kobelco SK495D excavator offers reliable performance for demanding earthmoving and construction operations. Located in Zhejiang, China, this machine represents solid value in the 50-ton class crawler excavator segment. The SK495D is engineered with Kobelco's proven hydraulic systems and fuel-efficient powertrain, designed to deliver productivity in mining, quarrying, and heavy civil projects.

Key features of the Kobelco SK495D include:

  • Operating weight approximately 49,500 kg
  • Powerful engine delivering strong digging force
  • Advanced hydraulic system for smooth operation
  • Spacious operator cab with good visibility
  • Durable undercarriage built for tough terrain

This unit has been maintained in working condition and is ready for inspection. Suitable for contractors and operators requiring a large excavator with proven Japanese engineering. Contact us directly to discuss specifications, current condition, and export arrangements.

SpecificationsValue
No.1172739
Tonnage (tons)49
Working weight (kg)52700
Bucket capacity (m³)2.3
Boom length (mm)7000
Rod length (mm)3000
Country of originChengdu
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeHino P11C
Rated power (kw/rpm)257/1850
Cooling modewater-cooling
Cylinder diameter × stroke (mm)122 x 150
Maximum torque (N.m)1400
Number of cylinders (PCS)6
Displacement (L)10.52
Working formDirect injection, water-cooled, four-stroke, turbocharged, built-in intercooling
Rotation speed (rpm)7.8
Climbing ability (%)70% (35°)
Bucket digging force (kN)266
Rod digging force (kN)223
Maximum tractive force (kN)417
Travel speed (km/h)5.4/3.4
Maximum flow of main pump (l/min)2 x 370
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)25
Control Hydraulic Circuit (Mpa)5
Main pump typeDual variable displacement axial piston pump
Working Hydraulic Circuit (Mpa)31.4
Fuel Tank (L)650
Hydraulic Tank (L)300
Engine Oil changes (L)50
Coolant (L)41
Hydraulic System (L)555
Total transport length (mm)12080
Total transport width (mm)3570
Total transport height (mm)3800
Minimum ground clearance (mm)510
Minimum turning radius of front working device (mm)5270
Back end turning radius (mm)3670
Total track length (mm)5460
Total track width (mm)3130
Maximum height at minimum turning radius (mm)9003
Maximum digging radius (mm)11770
Maximum digging depth (mm)7360
Maximum excavation height (mm)11160
Maximum unloading height (mm)7720
Maximum vertical digging depth (mm)6680
Maximum excavation radius of stop surface (mm)11540
see more

Overview

No.1172739

Brand Name:

Kobelco

Model Number:

SK495D

Year:

2018

Location:

Zhejiang China

Pub Date:
