2017 Kobelco SK75

1/8
Buy Kobelco SK75 Used Excavator / 1
Buy Kobelco SK75 Used Excavator / 2
Buy Kobelco SK75 Used Excavator / 3
Buy Kobelco SK75 Used Excavator / 4
Buy Kobelco SK75 Used Excavator / 5
Buy Kobelco SK75 Used Excavator / 6
Buy Kobelco SK75 Used Excavator / 7
Buy Kobelco SK75 Used Excavator / 8

Product Description

This 2017 Kobelco SK75 compact excavator from Zhejiang, China represents reliable performance from a trusted Japanese manufacturer. Delivered in November 2017, this 7.5-ton class machine offers the versatility and efficiency required for construction, landscaping, and utility applications. The SK75 is known for its excellent hydraulic flow, operator comfort, and fuel efficiency in its weight category.

Key features of the Kobelco SK75 include:

  • Compact footprint ideal for confined jobsites
  • Zero tail swing design for enhanced maneuverability
  • Robust undercarriage and track system
  • Efficient diesel engine meeting emission standards
  • Well-maintained operational condition

Detailed photos and operational videos are available for review. On-site inspection and test operation can be arranged for serious buyers. This machine is ready for immediate deployment in your equipment fleet.

SpecificationsValue
No.1174365
Tonnage (tons)7
Working weight (kg)7000(approx)
Country of originChengdu
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeISUZU AU4LE2X
Rated power (kw/rpm)41/2200
Cooling modewater-cooling
Cylinder diameter × stroke (mm)85 x 96
Number of cylinders (PCS)4
Displacement (L)2.179
Rotary hydraulic motor typeAxial piston motor
Traveling Hydraulic Circuit (Mpa)27.5
Rotary Hydraulic Circuit (Mpa)14.5
Control Hydraulic Circuit (Mpa)3.5
Main pump typeDouble variable displacement axial piston pump + pilot gear pump
Working Hydraulic Circuit (Mpa)29.4
Fuel Tank (L)120
Hydraulic Tank (L)72
Engine Oil changes (L)11
Coolant (L)8.5
Hydraulic System (L)120
Total transport height (mm)2630
Full cab height (mm)2630
Minimum turning radius of front working device (mm)1760
Back end turning radius (mm)1290
Maximum digging radius (mm)6460
Maximum digging depth (mm)4160
Maximum excavation height (mm)7390
Maximum unloading height (mm)5330
Maximum vertical digging depth (mm)3450
Maximum excavation radius of stop surface (mm)6300
Maximum effective digging depth (mm)3800
Travel speed (km/h)2.8/5.3
see more

Overview

No.1174365

Brand Name:

Kobelco

Model Number:

SK75

Year:

2017

Location:

Zhejiang China

Pub Date:
