2018 Kobelco SK75

1/9
Buy Kobelco SK75 Used Excavator / 1
Buy Kobelco SK75 Used Excavator / 2
Buy Kobelco SK75 Used Excavator / 3
Buy Kobelco SK75 Used Excavator / 4
Buy Kobelco SK75 Used Excavator / 5
Buy Kobelco SK75 Used Excavator / 6
Buy Kobelco SK75 Used Excavator / 7
Buy Kobelco SK75 Used Excavator / 8
Buy Kobelco SK75 Used Excavator / 9

Product Description

This 2018 Kobelco SK75SR-3 midi excavator represents proven Japanese engineering at an accessible price point. With approximately 6 years of service, this machine delivers the reliability and fuel efficiency that made the SK75 series an industry standard for utility work, landscaping, and light construction applications.

Key features of this unit include:

  • Isuzu 4-cylinder diesel engine delivering dependable performance
  • 7.5-tonne operating weight suited for confined work areas
  • Zero tail swing design for superior maneuverability in tight spaces
  • Hydraulic system engineered for smooth, precise control
  • Robust undercarriage with durable track components

Currently located in Anhui, China, this SK75 is available for immediate inspection and export. The machine has been maintained in working condition and is ready for deployment. Contact us for detailed specifications, current photos, and shipping arrangements to your location.

SpecificationsValue
No.1171319
Tonnage (tons)7
Working weight (kg)7000(approx)
Country of originChengdu
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeISUZU AU4LE2X
Rated power (kw/rpm)41/2200
Cooling modewater-cooling
Cylinder diameter × stroke (mm)85 x 96
Number of cylinders (PCS)4
Displacement (L)2.179
Rotary hydraulic motor typeAxial piston motor
Traveling Hydraulic Circuit (Mpa)27.5
Rotary Hydraulic Circuit (Mpa)14.5
Control Hydraulic Circuit (Mpa)3.5
Main pump typeDouble variable displacement axial piston pump + pilot gear pump
Working Hydraulic Circuit (Mpa)29.4
Fuel Tank (L)120
Hydraulic Tank (L)72
Engine Oil changes (L)11
Coolant (L)8.5
Hydraulic System (L)120
Total transport height (mm)2630
Full cab height (mm)2630
Minimum turning radius of front working device (mm)1760
Back end turning radius (mm)1290
Maximum digging radius (mm)6460
Maximum digging depth (mm)4160
Maximum excavation height (mm)7390
Maximum unloading height (mm)5330
Maximum vertical digging depth (mm)3450
Maximum excavation radius of stop surface (mm)6300
Maximum effective digging depth (mm)3800
Travel speed (km/h)2.8/5.3
