Product Description
This 2019 Kobelco SK75 compact excavator is available from Jiangxi, China. The machine features original factory bodywork with intact hydraulic lines and an undercarriage in excellent condition showing minimal wear. Factory air conditioning is retained for operator comfort during extended shifts.
The SK75 is known for reliable performance in confined work areas, making it suitable for urban construction, utility installation, and landscaping projects. This unit demonstrates strong operational capability and is ready for on-site inspection and test operation.
- Year: 2019
- Model: Kobelco SK75
- Condition: Used, well-maintained
- Location: Jiangxi Province, China
- Features: Original hydraulic system, factory A/C, excellent undercarriage
- Availability: Immediate inspection and demonstration available
Serious buyers are invited to arrange site visits for hands-on evaluation.
| Specifications | Value |
|---|---|
| No. | 1072553 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7000(approx) |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU AU4LE2X |
| Rated power (kw/rpm) | 41/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 85 x 96 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.179 |
| Rotary hydraulic motor type | Axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 27.5 |
| Rotary Hydraulic Circuit (Mpa) | 14.5 |
| Control Hydraulic Circuit (Mpa) | 3.5 |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 72 |
| Engine Oil changes (L) | 11 |
| Coolant (L) | 8.5 |
| Hydraulic System (L) | 120 |
| Total transport height (mm) | 2630 |
| Full cab height (mm) | 2630 |
| Minimum turning radius of front working device (mm) | 1760 |
| Back end turning radius (mm) | 1290 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4160 |
| Maximum excavation height (mm) | 7390 |
| Maximum unloading height (mm) | 5330 |
| Maximum vertical digging depth (mm) | 3450 |
| Maximum excavation radius of stop surface (mm) | 6300 |
| Maximum effective digging depth (mm) | 3800 |
| Travel speed (km/h) | 2.8/5.3 |
