Product Description
This 2019 Kobelco SK75 midi excavator offers reliable performance for contractors seeking proven Japanese engineering. Currently located in Jiangxi, China, this machine represents excellent value in the used equipment market.
The SK75 is well-regarded for its 7.5-ton operating weight class, delivering efficient digging performance while maintaining compact dimensions for confined jobsites. This unit comes equipped with a bucket attachment and shows well-maintained cosmetic condition consistent with light commercial use.
- Year: 2019
- Make: Kobelco
- Model: SK75
- Includes bucket attachment
- Location: Jiangxi Province, China
Kobelco's SK75 series features straightforward hydraulic systems and serviceable components, making it suitable for general earthmoving, utility work, and construction applications. This machine is competitively priced for its age and condition. Contact us for detailed specifications, inspection reports, and shipping arrangements.
| Specifications | Value |
|---|---|
| No. | 1162983 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7000(approx) |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU AU4LE2X |
| Rated power (kw/rpm) | 41/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 85 x 96 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.179 |
| Rotary hydraulic motor type | Axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 27.5 |
| Rotary Hydraulic Circuit (Mpa) | 14.5 |
| Control Hydraulic Circuit (Mpa) | 3.5 |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 72 |
| Engine Oil changes (L) | 11 |
| Coolant (L) | 8.5 |
| Hydraulic System (L) | 120 |
| Total transport height (mm) | 2630 |
| Full cab height (mm) | 2630 |
| Minimum turning radius of front working device (mm) | 1760 |
| Back end turning radius (mm) | 1290 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4160 |
| Maximum excavation height (mm) | 7390 |
| Maximum unloading height (mm) | 5330 |
| Maximum vertical digging depth (mm) | 3450 |
| Maximum excavation radius of stop surface (mm) | 6300 |
| Maximum effective digging depth (mm) | 3800 |
| Travel speed (km/h) | 2.8/5.3 |
