2020 Kobelco SK75

1/3
Buy Kobelco SK75 Used Excavator / 1
Buy Kobelco SK75 Used Excavator / 2
Buy Kobelco SK75 Used Excavator / 3

Product Description

This 2020 Kobelco SK75 midi excavator is now available from Sichuan, China. The SK75 is a proven 7.5-ton class machine known for reliable hydraulic performance and fuel efficiency in construction and earthmoving applications. This unit has accumulated operating hours consistent with light to moderate site work and remains in functional condition for continued service.

Key features of the Kobelco SK75 include:

  • Compact footprint suitable for urban construction sites
  • Powerful Isuzu engine with low emission compliance
  • Advanced hydraulic system for precise control
  • Comfortable operator cabin with clear visibility
  • Durable undercarriage designed for varied terrain

Currently located in Sichuan Province, this excavator is available for inspection by appointment. Pricing reflects its pre-owned status and current market conditions. Contact us for detailed specifications, service records, and export documentation assistance.

SpecificationsValue
No.1143724
Tonnage (tons)7
Working weight (kg)7000(approx)
Country of originChengdu
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeISUZU AU4LE2X
Rated power (kw/rpm)41/2200
Cooling modewater-cooling
Cylinder diameter × stroke (mm)85 x 96
Number of cylinders (PCS)4
Displacement (L)2.179
Rotary hydraulic motor typeAxial piston motor
Traveling Hydraulic Circuit (Mpa)27.5
Rotary Hydraulic Circuit (Mpa)14.5
Control Hydraulic Circuit (Mpa)3.5
Main pump typeDouble variable displacement axial piston pump + pilot gear pump
Working Hydraulic Circuit (Mpa)29.4
Fuel Tank (L)120
Hydraulic Tank (L)72
Engine Oil changes (L)11
Coolant (L)8.5
Hydraulic System (L)120
Total transport height (mm)2630
Full cab height (mm)2630
Minimum turning radius of front working device (mm)1760
Back end turning radius (mm)1290
Maximum digging radius (mm)6460
Maximum digging depth (mm)4160
Maximum excavation height (mm)7390
Maximum unloading height (mm)5330
Maximum vertical digging depth (mm)3450
Maximum excavation radius of stop surface (mm)6300
Maximum effective digging depth (mm)3800
Travel speed (km/h)2.8/5.3
see more

Overview

No.1143724

Brand Name:

Kobelco

Model Number:

SK75

Year:

2020

Location:

Sichuan China

Pub Date
