Product Description
This 2020 Kobelco SK75 mini excavator delivers reliable performance for medium-duty construction and earthmoving applications. Built by one of Japan's leading hydraulic excavator manufacturers, this compact machine combines efficient fuel consumption with robust digging power in its 7.5-ton class. The SK75 features a reduced tail swing design for operation in confined spaces, making it ideal for urban construction sites, utility work, and landscaping projects.
Currently located in Hunan, China, this unit represents solid value in the used equipment market. Key specifications include:
- Operating weight: approximately 7,500 kg
- Engine power: meets regional emission standards
- Hydraulic system optimized for smooth operation
- Compact footprint with excellent maneuverability
- Suitable for trenching, grading, and material handling
This Kobelco SK75 offers dependable Japanese engineering at a competitive price point for contractors and equipment dealers seeking quality pre-owned machinery.
| Specifications | Value |
|---|---|
| No. | 1157809 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7000(approx) |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU AU4LE2X |
| Rated power (kw/rpm) | 41/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 85 x 96 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.179 |
| Rotary hydraulic motor type | Axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 27.5 |
| Rotary Hydraulic Circuit (Mpa) | 14.5 |
| Control Hydraulic Circuit (Mpa) | 3.5 |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 72 |
| Engine Oil changes (L) | 11 |
| Coolant (L) | 8.5 |
| Hydraulic System (L) | 120 |
| Total transport height (mm) | 2630 |
| Full cab height (mm) | 2630 |
| Minimum turning radius of front working device (mm) | 1760 |
| Back end turning radius (mm) | 1290 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4160 |
| Maximum excavation height (mm) | 7390 |
| Maximum unloading height (mm) | 5330 |
| Maximum vertical digging depth (mm) | 3450 |
| Maximum excavation radius of stop surface (mm) | 6300 |
| Maximum effective digging depth (mm) | 3800 |
| Travel speed (km/h) | 2.8/5.3 |
