Product Description
This 2019 Komatsu PC110-7 hydraulic excavator represents a solid mid-size option for contractors seeking reliable performance in construction, utility work, and general excavation applications. With approximately 9,800 operating hours from a single owner, this machine demonstrates consistent maintenance history and operational transparency.
The PC110 series is engineered for fuel efficiency and productivity in the 11-ton class, featuring Komatsu's proven hydraulic system and durable undercarriage components. Currently located in Shandong, China, this excavator offers excellent value for regional operations requiring dependable earthmoving capacity.
- Year: 2019
- Model: Komatsu PC110-7
- Hours: 9,800
- Ownership: Single owner
- Location: Shandong, China
Ideal for contractors prioritizing operational history and established brand reliability in the compact-to-midsize excavator segment.
| Specifications | Value |
|---|---|
| No. | 1144210 |
| Tonnage (tons) | 11 |
| Working weight (kg) | 11300 |
| Bucket capacity (m³) | 0.48-0.53 |
| Boom length (mm) | 4260 |
| Rod length (mm) | 2360 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA4D95LE-5 |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 95 x 115 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.26 |
| Working form | Four-cylinder four-stroke turbocharged intercooled direct injection engine |
| Ground specific pressure (Kpa) | 38 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 92.7 |
| Rod digging force (kN) | 59.8 |
| Maximum tractive force (kN) | 122.6 |
| Travel speed (km/h) | 2.8/5.5 |
| Maximum flow of main pump (l/min) | 242 |
| Traveling Hydraulic Circuit (Mpa) | 34.8 |
| Rotary Hydraulic Circuit (Mpa) | 29.2 |
| Main pump type | Variable piston pump *2 |
| Working Hydraulic Circuit (Mpa) | 31.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-90 x 885 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-115 x 997 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-95 x 980 |
| Fuel Tank (L) | 247 |
| Hydraulic Tank (L) | 145 (90) |
| Engine Oil changes (L) | 13 |
| Total transport length (mm) | 7160 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2855 |
| Full cab height (mm) | 2815 |
| Counterweight ground clearance (mm) | 855 |
| Minimum ground clearance (mm) | 400 |
| Minimum turning radius of front working device (mm) | 2430 |
| Back end turning radius (mm) | 2190 |
| Onboard width (mm) | 2500 |
| Total track length (mm) | 3435 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 2700 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 6 |
| Number of track plates (single side) (PCS) | 41 |
| Maximum digging radius (mm) | 7730 |
| Maximum digging depth (mm) | 5060 |
| Maximum excavation height (mm) | 7910 |
| Maximum unloading height (mm) | 5650 |
| Maximum vertical digging depth (mm) | 4570 |
| Maximum excavation radius of stop surface (mm) | 7600 |
