Product Description
Engineered with Komatsu's proven SAA4D95LE-3 engine delivering 66kW at 2200 rpm, this PC130-7 excavator combines precision hydraulics with robust performance. The water-cooled, turbocharged, and intercooled diesel system operates through a 3.26L displacement, driving a maximum main pump flow of 226 l/min across optimized hydraulic circuits (32 MPa working, 35 MPa traveling). With a 12,600 kg working weight and 0.53 m³ bucket capacity, this 13-ton machine achieves exceptional digging forces—93.2 kN bucket force and 61.8 kN arm force—supported by a 2100mm rod length.
Performance specifications include:
- Maximum digging reach: 8290mm with 5520mm depth capability
- Superior climbing ability: 70% gradient (30°)
- Travel speeds: 2.7-5.5 km/h for efficient site mobility
- Compact dimensions: 7599mm transport length, 2175mm height
- Ground pressure: 38 kPa minimizes surface disturbance
Joint venture manufacturing ensures Komatsu's quality standards throughout. Currently located in Guangdong Meizhou, this 2016 unit represents proven hydraulic excavator technology ready for demanding earthmoving applications worldwide.
| Specifications | Value |
|---|---|
| No. | 1024411 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12600 |
| Bucket capacity (m³) | 0.53 |
| Rod length (mm) | 2100 |
| Country of origin | Jining, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA4D95LE-3 |
| Rated power (kw/rpm) | 66/2200 |
| Cooling mode | water-cooling |
| Displacement (L) | 3.26 |
| Working form | Direct injection, turbocharged, intercooled diesel engine |
| Ground specific pressure (Kpa) | 38 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70/30 ° |
| Bucket digging force (kN) | 93.2 |
| Rod digging force (kN) | 61.8 |
| Travel speed (km/h) | 2.7-5.5 |
| Maximum flow of main pump (l/min) | 226 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 29 |
| Control Hydraulic Circuit (Mpa) | 30 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 32 |
| Fuel Tank (L) | 247 |
| Hydraulic Tank (L) | 90 |
| Engine Oil changes (L) | 11 |
| Coolant (L) | 13.4 |
| Total transport length (mm) | 7599 |
| Total transport height (mm) | 2175 |
| Full cab height (mm) | 2175 |
| Counterweight ground clearance (mm) | 855 |
| Minimum ground clearance (mm) | 400 |
| Back end turning radius (mm) | 2110 |
| Total track length (mm) | 3610 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2880 |
| Maximum digging radius (mm) | 8290 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8610 |
| Maximum unloading height (mm) | 6170 |
| Maximum vertical digging depth (mm) | 4940 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 8170 |
| Maximum effective digging depth (mm) | 5315 |
