Product Description
This 2020 Komatsu PC160-7 excavator is available now from our Zhejiang, China location. This locally-sourced machine comes equipped with a hydraulic breaker attachment, offering enhanced versatility for demolition and breaking applications. With over 40,000 hours of documented operation, this unit represents a cost-effective solution for contractors seeking proven Komatsu reliability at an accessible price point.
Key features include:
- Komatsu PC160-7 mid-size excavator platform
- Hydraulic breaker attachment included
- Complete documentation and service records on file
- Ready for immediate loading and shipment
- Local inventory in Zhejiang Province
All paperwork has been verified and completed. This machine is cleared for export and available for inspection by appointment. Contact our sales team for detailed specifications, current condition reports, and shipping arrangements to your location.
| Specifications | Value |
|---|---|
| No. | 1170613 |
| Tonnage (tons) | 16 |
| Working weight (kg) | 16500 |
| Bucket capacity (m³) | 0.65 |
| Boom length (mm) | 5150 |
| Rod length (mm) | 2610 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA4D102E-2 |
| Rated power (kw/rpm) | 82.4/2200 |
| Cooling mode | water-cooling |
| Displacement (L) | 3.92 |
| Working form | 4 cylinder, direct injection, turbocharged, after cooling, mechanical full speed control; Comply with 2001 EPA/EU/ Japan Level 2 emission standards. |
| Ground specific pressure (Kpa) | 46.1 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 123 |
| Rod digging force (kN) | 86.3 |
| Travel speed (km/h) | 3.4-5.5 |
| Rotary hydraulic motor type | Axial piston motor ×1(rotary holding valve) |
| Type of walking hydraulic motor | Axial piston motor ×2(with parking brake) |
| Maximum flow of main pump (l/min) | 312 |
| Traveling Hydraulic Circuit (Mpa) | 37.3 |
| Rotary Hydraulic Circuit (Mpa) | 28.4 |
| Control Hydraulic Circuit (Mpa) | 3.2 Pilot oil circuit |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 37.3 |
| Bucket cylinders - Number × diameter × stroke (mm) | 105 * 1027 * 70 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 120 * 1342 * 85 |
| Boom cylinders - Number × diameter × stroke (mm) | 110 * 1175 * 75 |
| Fuel Tank (L) | 280 |
| Hydraulic Tank (L) | 121 |
| Engine Oil changes (L) | 14 |
| Coolant (L) | 17.3 |
| Total transport length (mm) | 8565 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2990 |
| Full cab height (mm) | 2970 |
| Counterweight ground clearance (mm) | 1055 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2390 |
| Total track length (mm) | 3965 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 3170 |
| Maximum digging radius (mm) | 8960 |
| Maximum digging depth (mm) | 5960 |
| Maximum excavation height (mm) | 8980 |
| Maximum unloading height (mm) | 6370 |
| Maximum vertical digging depth (mm) | 5040 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Maximum effective digging depth (mm) | 5740 |
