Product Description
This 2020 Komatsu PC200-8N1 is an imported unit currently held in Guangxi, China, and offered for sale from our yard stock. It sits in the 20-tonne operating class that has made the PC200 series a default choice on earthmoving, roadworks and general civil construction sites, and imported units of this vintage remain a practical option for contractors who need proven iron without new-machine pricing.
- Year: 2020
- Brand / Model: Komatsu PC200-8N1
- Origin: imported unit
- Class: 20-tonne hydraulic excavator
- Location: Guangxi, China — on-site inspection welcome
- Price indication: upper tens-of-thousands RMB
Mechanical condition, working hours and undercarriage wear are best confirmed on inspection, and we will supply photographs, video walkaround and component details on request. The machine is sold as inspected. Chinese domestic purchase and export arrangements can both be discussed; loading and documentation support is available for overseas buyers. Buyers are welcome to send an engineer or third-party surveyor to the yard in Guangxi before committing. Please quote the model reference in any enquiry so we can respond with current availability and terms.
| Specifications | Value |
|---|---|
| No. | 1157647 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 19500 |
| Bucket capacity (m³) | 0.8 |
| Rod length (mm) | 2900 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA6D107E-1-A |
| Rated power (kw/rpm) | 110/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.69 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 44.1 |
| Rotation speed (rpm) | 12.4 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 108 |
| Travel speed (km/h) | 5.5/4.1/3.0 |
| Rotary hydraulic motor type | Fixed displacement axial piston motor |
| Type of walking hydraulic motor | Variable axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 37.3 |
| Working Hydraulic Circuit (Mpa) | 34.8 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 135 |
| Hydraulic System (L) | 232 |
| Total transport length (mm) | 9425 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3040 |
| Minimum turning radius of front working device (mm) | 3040 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 9875 |
| Maximum digging depth (mm) | 6620 |
| Maximum excavation height (mm) | 10000 |
| Maximum unloading height (mm) | 1110 |
| Maximum excavation radius of stop surface (mm) | 9700 |
